Description
The HPE Networking Comware 12902E (JH345A) is a high-performance, 4-slot modular switch chassis purpose-built for modern data center cores and cloud deployments. Supporting next-gen H2 modules with 100/400GbE speeds, this 3U chassis delivers up to 19.2 Tbps switching capacity and 11.5 Bpps throughput. It is designed for unmatched scalability, distributed architecture, and advanced Layer 2/3 features with Comware v9, including VXLAN, EVPN, and full IPv4/IPv6 routing.
With two MPU slots and two I/O module slots, the 12902E offers investment protection, enterprise-grade availability, and multi-tenancy support—ideal for telcos, large enterprises, and service providers transforming their networks.
| Specification | Details |
|---|---|
| Product Number | JH345A |
| Chassis Form Factor | 4-slot horizontal chassis, 3U rackmount |
| Slots | 2 MPU slots, 2 I/O module slots |
| Port Capacity | Up to 96 × 100/40/10/1 GbE ports or 48 × 1/10GBASE-T ports |
| Switching Capacity | 19.2 Tbps |
| Throughput | Up to 11.5 Bpps |
| Latency | < 5 microseconds (64-byte packets) |
| Routing Features | IPv4, IPv6, BGP, OSPF, MPLS, RIP, VPLS, IS-IS, ECMP, uRPF |
| Management Options | CLI, IMC, SNMP, Telnet, RS-232C, Ethernet MIB |
| Memory & Processor | Quad Core MIPS64 @ 1GHz, 1GB flash, 8GB DDR3 SDRAM |
| Power Supply Slots | 16 slots (1 required, ordered separately) |
| Input Voltage | 100–240 VAC or -48 to -60 VDC (model dependent) |
| Power Consumption | 1800W |
| Operating Humidity Range | 5% to 95% (non-condensing) |
| Dimensions (W × D × H) | 44.0 × 89.5 × 13.3 cm |
| Weight | 24 kg |
