Description
The HPE Networking Instant On 1430 16-Port PoE Switch is a plug-and-play unmanaged Gigabit Ethernet switch designed for small businesses and home offices that need reliable, affordable, and hassle-free network connectivity. Delivering 16 autosensing Class 4 PoE-enabled ports with a total power budget of 124W, this switch is ideal for connecting IP phones, wireless access points, and IoT devices. The fanless design ensures silent operation, while its compact form factor supports rack, wall, and desktop mounting. With no configuration required, it’s a true zero-maintenance solution for growing small business networks.
| Feature | Details |
|---|---|
| Product Code | R8R48A#ABA |
| Product Type | Unmanaged Gigabit Ethernet Switch |
| Ports | 16 x RJ-45 autosensing 10/100/1000 Mbps (PoE Class 4) |
| Switching Capacity | 32 Gbps |
| Throughput | 23.80 Mpps |
| PoE Budget | 124W total power, Class 4 PoE (IEEE 802.3af/at compliant) |
| Memory & Buffer | 128 Kb EEPROM, 2.0 Mb packet buffer |
| Power Supply | External Power Adapter |
| Power Consumption | Max: 147W, Idle: 5W |
| Input Voltage | 100–127VAC / 200–240VAC |
| Mounting Options | Desktop, rack-mountable, wall-mountable |
| Cooling | Fanless design |
| Dimensions (W x D x H) | 10.24 x 10.83 x 1.73 in (260 x 275 x 44 mm) |
| Weight | 4.60 lb (2.09 kg) |
| Management | Unmanaged |
| Use Case | Small businesses, home offices, plug-and-play network deployments |
