Description
The HPE Networking Instant On 1830 8-Port Gigabit PoE+ 65W Smart Switch is designed for small businesses that require cost-effective, easy-to-manage wired connectivity. Featuring eight Gigabit ports with Class 4 PoE+ support, this smart-managed Layer 2 switch delivers reliable power and data to critical devices such as IP phones, wireless access points, and security cameras—without additional cabling.
Built with quiet, fanless operation and flexible management options—including the Instant On cloud portal and local web GUI—this compact switch is ideal for acoustically sensitive environments. With 65W of total PoE power, energy-efficient features, VLAN support, and built-in security, the JL811A#ABA is the perfect fit for growing networks with limited budgets.
| Specification | Details |
|---|---|
| Product Number | JL811A#ABA |
| Model | HPE Networking Instant On 1830 8G Class 4 PoE 65W Switch |
| Ports | 8 x RJ-45 10/100/1000 Mbps (Class 4 PoE+) |
| PoE Power Budget | 65W |
| Switching Capacity | 16 Gbps |
| Throughput | 11.90 Mpps |
| Packet Buffer | 1.5 MB |
| Memory | 512 MB SDRAM / 256 MB Flash |
| Processor | ARM Cortex-A9 @ 800MHz |
| Power Supply | Internal, 100 – 240 VAC input |
| Power Consumption | Max: 86.07W (100–127V), 83.67W (200–220V) |
| Idle Power | 8.3W (100–127V), 8.2W (200–220V) |
| Management Interfaces | Instant On Cloud, Web GUI, SNMP |
| Security | VLANs, DoS protection, TPM, Global Storm Control |
| Energy Efficiency | IEEE 802.3az (Energy Efficient Ethernet), PoE Scheduling |
| Form Factor | Desktop or rack-mountable, fanless |
| Dimensions (WxDxH) | 7.68 x 9.65 x 1.73 in |
| Weight | 3.40 lb |
