Description
The HPE Networking Comware Router 4 AC MSR1002X (R8V33A) is a next-generation multi-service router designed for small branches and remote offices needing high performance, flexibility, and simplified management. With forwarding performance up to 500 Kpps, advanced Comware v7 OS, and integrated features including routing, switching, security, and SIP/voice, this router delivers scalable network performance without additional licensing fees.
Equipped with 2 SIC module slots, 4 LAN ports, 1 WAN port, and 1 SFP port, the MSR1002X supports a wide range of connectivity options including 3G/4G LTE, and delivers future-ready services like OpenFlow SDN, VXLAN, IPSec VPN, ADVPN, MPLS, and IPv6. Ideal for businesses seeking a cost-effective platform with built-in security and zero-touch deployment.
| Specification | Details |
|---|---|
| Model Number | R8V33A |
| Product Name | HPE Networking Comware Router 4 AC MSR1002X |
| Operating System | Comware v7 |
| Performance | Up to 500 Kpps throughput |
| Routing Table Size | 90,000 (IPv4), 90,000 (IPv6) |
| Forwarding Table Size | 90,000 (IPv4), 90,000 (IPv6) |
| Processor & Memory | RISC @ 1.6 GHz, 1 GB DDR3 SDRAM, 256 MB flash |
| I/O Ports | 1x RJ-45 WAN, 4x RJ-45 LAN, 1x SFP, 2x SIC slots, 1x USB 2.0, 1x Console |
| Mounting | Desktop or 1U rack-mountable (kit included) |
| Dimensions (W x D x H) | 14.17 x 11.81 x 1.74 in (36 x 30 x 4.42 cm) |
| Weight | 10.69 lb (4.85 kg) |
| Power Supply | AC, 100–240V, 50/60Hz |
| Power Consumption | Max 30 W |
| Heat Dissipation | Max 65 BTU/hr |
| Operating Temp / Humidity | 0°C to 45°C / 5%–95% (non-condensing) |
| Compliance | UL, FCC, CE, VCCI, CISPR, RoHS, WEEE |
| Management | IMC, CLI, SNMPv1/v2/v3, Telnet, RMON, FTP |
| Security Features | ADVPN, IPSec VPN, NAT, ACL, SSH, TACACS+, Firewall |
| Advanced Features | MPLS, OpenFlow, VRRP, WAN Optimization, VXLAN, SDN |
