Description
The HPE FlexNetwork MSR2004-24 AC Router is a high-performance, modular enterprise-class router designed for medium branch environments. Featuring 24 Gigabit Ethernet LAN ports, integrated routing, switching, security, and voice services without the need for additional licensing, this router simplifies WAN infrastructure and boosts service delivery.
With forwarding performance up to 4 Mpps and hardware-based encryption, firewall, NAT, and VPN capabilities, the MSR2004-24 ensures secure and resilient connectivity. Its flexible modular design supports multiple SIC slots and both copper and SFP uplinks, enabling tailored solutions that scale with evolving network needs. Zero-touch deployment and integration with HPE Intelligent Management Center (IMC) provide centralized control and efficiency.
Whether supporting branch office connectivity or enabling hybrid cloud services, the MSR2004-24 AC delivers powerful features, simplified management, and long-term value.
Key Features
-
24 autosensing 10/100/1000 RJ-45 ports
-
Up to 4 Mpps forwarding performance
-
Integrated switching, routing, firewall, VPN, and voice
-
Modular platform with 4 SIC slots and SFP support
-
Hardware-based encryption and security features
-
Zero-touch deployment and single-pane-of-glass management
-
Energy-efficient with compact 1U rack-mountable design
| Specification | Details |
|---|---|
| Model | HPE FlexNetwork MSR2004-24 AC Router |
| Part Number | JG734A#ABA |
| Ports | 24x 10/100/1000 RJ-45 LAN, 3x 1000BASE-T, 1x SFP, 4x SIC slots |
| Forwarding Performance | Up to 4 Mpps |
| Security | Hardware-based encryption, firewall, NAT, VPN |
| Voice Support | Integrated SIP and voice features |
| Power Input | 100 – 240 VAC (rated) |
| Power Consumption | 54 W (maximum) |
| Heat Dissipation | 170 BTU/hr |
| Form Factor | Rack-mountable, 1U |
| Dimensions (W x D x H) | 17.32 x 14.17 x 1.74 in (440 x 360 x 44 mm) |
| Weight | 15.1 lb (6.85 kg) |
| Management | HPE IMC, Zero-touch provisioning, Comware v7 |
| Wireless Capable | Optional, depending on configuration |
| Ideal Use Case | Medium branch offices, integrated WAN, cloud edge environments |
