Description
The Cisco Catalyst IE-3100-8P2C-E is a rugged, compact industrial Ethernet switch designed for harsh and space-constrained environments. It delivers reliable Gigabit Ethernet connectivity with integrated Power over Ethernet Plus (PoE+) to support industrial IoT devices, cameras, access points, sensors, and controllers.
Built for extended enterprise and industrial deployments, this fixed-configuration switch features 8 Gigabit Ethernet PoE+ copper ports and 2 Gigabit Ethernet combo uplink ports, providing flexible connectivity and simplified network design. It operates on Cisco IOS XE with a Network Essentials license, offering strong Layer 2 switching, basic Layer 3 capabilities, industrial protocols, and enterprise-grade security.
With a fanless, DIN-rail-mountable design, dual DC power inputs, and wide operating temperature support, the IE-3100-8P2C-E is ideal for manufacturing floors, transportation systems, energy infrastructure, smart cities, and outdoor industrial installations where reliability and resilience are critical.
| Specification | Details |
|---|---|
| Model | Cisco Catalyst IE-3100-8P2C-E |
| Switch Type | Industrial Ethernet, Fixed Configuration |
| Downlink Ports | 8 × Gigabit Ethernet PoE+ (RJ-45) |
| Uplink Ports | 2 × Gigabit Ethernet Combo (RJ-45/SFP) |
| PoE Support | IEEE 802.3af / 802.3at |
| Total PoE Budget | Up to 240 W |
| Software | Cisco IOS XE |
| License Level | Network Essentials |
| Switching Capacity | Up to 20 Gbps |
| Forwarding Rate | Up to 29.76 Mpps |
| Memory | 4 GB DRAM |
| Storage | Optional SD card support |
| Power Input | Dual DC inputs |
| Cooling | Fanless, convection-cooled |
| Mounting | DIN rail |
| Operating Temperature | Designed for harsh industrial environments |
| Form Factor | Compact, ruggedized enclosure |
| Typical Use Cases | Industrial IoT, automation, transportation, utilities, smart cities |
