Description
The Chief MIWRF6000B In-Wall Swing Arm is a fully integrated, pre-assembled mounting solution designed to deliver a clean, low-profile installation with maximum positioning flexibility. Engineered to install flush inside the wall, this in-wall mount supports flat panel displays from 30 to 50 inches weighing up to 125 lbs, while maintaining a finished depth of less than 2 inches.
Installation is streamlined with a pre-assembled in-wall box that fits between standard 16-inch center studs without cutting studs or adding headers or footers. Built-in lateral shift and post-installation height adjustment allow precise centering and final alignment, while integrated cable management and the included trim kit ensure a polished, professional appearance.
For optimal viewing, the MIWRF6000B offers smooth extension, wide swivel range, and fingertip tilt using Centris technology, allowing the display to stay exactly where you set it. This custom in-wall mount requires an MSB-series interface bracket and is backed by a 10-year warranty for long-term confidence.
Key Features
-
Fully integrated, pre-assembled in-wall swing arm design
-
Flush, low-profile installation with finished depth under 2 inches
-
Fits between 16" center studs with no stud cutting required
-
Built-in lateral shift for precise display centering
-
Post-installation height adjustment for fine tuning
-
Smooth swivel, extension, and fingertip tilt using Centris technology
-
Integrated cable management with included trim kit
-
ClickConnect system for tool-free display attachment and removal
-
Requires MSB-series interface bracket
-
Backed by a 10-year warranty
| Specification | Details |
|---|---|
| SKU | MIWRF6000B |
| Brand | Chief |
| Product Type | In-Wall Swing Arm Mount |
| Display Size Compatibility | 30" – 50" |
| Maximum Weight Capacity | Up to 125 lbs (56.7 kg) |
| VESA Compatibility | 100 × 100 mm to 709 × 431 mm |
| Mounting Location | In-Wall |
| Orientation Support | Landscape, Portrait |
| Swivel Range | Up to 37° left/right |
| Extension Range | Up to 15" |
| Tilt Adjustment | ±15° fingertip tilt |
| Lateral Shift | Up to 3.5" left or right |
| Height Adjustment | Up to 1" post-installation |
| Finish Profile | Low-profile, concealed behind display |
| Interface Requirement | MSB-Series Interface Bracket (required) |
| Warranty | 10 Years |
