Description
The Allied Telesis x550-18XTQ is a high-performance 10G/40G Layer 3 stackable switch, engineered for demanding network environments. Featuring 16 x 10G Ethernet ports and 2 x 40G QSFP+ uplinks, it’s the ideal solution for high-speed core and distribution networks. With full Layer 3 support, modular stacking, and intelligent management through Vista Manager™ and AMF, the x550-18XTQ simplifies administration while maximizing resiliency and performance. Its compact rack-mountable design and low power consumption make it perfect for modern enterprises and high-bandwidth applications.
Product Highlights:
-
16 x 10G Ethernet Ports
-
2 x 40G QSFP+ Uplinks
-
Modular and Stackable Design
-
Full Layer 3 Routing Support
-
Vista Manager™ EX & AMF for Simplified Management
-
High-speed 10G/40G Connectivity
-
128W Power Consumption
-
IEEE-compliant advanced networking standards
-
Supports Twisted Pair & Optical Fiber
-
Rack-mountable (1U Form Factor)
-
New and Factory Fresh
| Category | Details |
|---|---|
| Manufacturer | Allied Telesis, Inc |
| Model | x550-18XTQ |
| Part Number | AT-X550-18XTQ-J90 |
| Product Type | Layer 3 Stackable Switch |
| Ports | 16 x 10G Ethernet Ports |
| Uplink Ports | 2 x 40G QSFP+ Slots |
| Media Type Supported | Twisted Pair, Optical Fiber |
| Ethernet Technology | 10 Gigabit Ethernet, 40 Gigabit Ethernet |
| Network Technology | 10GBase-T, 40GBase-X |
| Manageable | Yes |
| Layer Support | Layer 3 |
| Modular / Stackable | Yes / Yes |
| Standards Compliance | IEEE 802.1x, 802.3ab, 802.3an, 802.3bz, 802.3ba, 802.1Q, 802.1AX, and more |
| Power Consumption | 128W |
| Form Factor | Rack-mountable (1U) |
| Dimensions (HxWxD) | 1.7” x 8.3” x 13.6” |
| Weight | 6.83 lbs (Shipping: 7 lbs) |
| Power Source | Internal Power Supply (1 included) |
| Package Contents | x550-18XTQ Switch, Rack Mount Brackets |
| Environmentally Friendly | Yes |
