Description
The Kramer WP-SW2-EN7/US-D(W) is a high-performance 4K AVoIP encoder wall-plate designed for modern AV-over-IP installations across corporate, education, government, and hospitality environments. Engineered for robust streaming over a standard 1GbE network, this compact two-gang in-wall unit delivers high-quality video up to 4K@60Hz (4:2:0) with ultra-low latency and visually lossless compression.
Featuring HDMI, USB-C, and 3.5mm analog audio inputs, it enables flexible content sources with automatic or manual input switching. Integrated audio embedding ensures clean signal transport, while an intuitive on-device display and front-panel buttons simplify control. The unit also supports powerful remote management via web interface, Protocol 3000, and full control gateway capabilities using RS-232 or CEC for connected devices.
With PoE support, secure HTTPS operation, and reliable construction in a white Decora-style frame, the WP-SW2-EN7/US-D(W) is an ideal solution for scalable AV-over-IP deployments that demand performance, convenience, and elegant installation.
| Category | Details |
|---|---|
| Inputs | 1 HDMI (female), 1 USB-C, 1 analog audio (3.5mm) |
| Ports | 2 Ethernet (RJ-45), 1 RS-232 (3-pin terminal block) |
| Streaming Format | Unicast & multicast over 1GbE |
| Video Compression | Visually lossless, JPEG2K-based proprietary codec |
| Max Input/Output Resolution | 4K@30Hz 4:4:4; End-to-end 4K@30Hz 4:4:4 |
| Supported Resolutions | 4096×2160@30Hz, 3840×2160@60Hz, 1920×1080@60Hz, 1280×720@60Hz, and more |
| Latency | 33 ms end-to-end |
| Switching Time | 1 second |
| Audio Support | LPCM up to 7.1/24-bit/192kHz, Dolby formats incl. Atmos, DTS formats incl. DTS-HD MA |
| Security | HTTPS, 802.1X, OWASP-10, AES-128 AV stream encryption |
| User Interface | HDMI/USB/Power LEDs, LCD channel display, CH+/CH− buttons, Reset |
| Power | PoE (37–57V) |
| Typical Power Consumption | 5.04W (67.68W with USB-C charging) |
| Enclosure Size | 2-gang, white Decora-style |
| Construction | SGCC steel + polycarbonate |
| Cooling | Convection ventilation |
| Dimensions (US) | 12.10 × 4.56 × 12.10 cm (4.76" × 1.80" × 4.76") |
| Weight (US) | 0.4 kg (1.0 lb) |
| Regulatory Compliance | CE, FCC, RoHS, WEEE |
