Description
The Allied Telesis CentreCOM GS980MX/18HSM is a powerful Layer 3 switch with 16 Multi-Gigabit PoE++ ports and dual 10G uplink slots. Designed to support next-generation applications such as high-speed Wi-Fi 6 access points, PTZ surveillance cameras, and bandwidth-intensive devices, this switch delivers enterprise-grade performance and scalability.
Featuring Virtual Chassis Stacking (VCStack™) for resilient deployments and offering PoE++ support up to 90W per port with a total PoE budget of 720W, the GS980MX/18HSM is ideal for industrial and enterprise environments requiring flexibility, reliability, and efficiency.
Its modular design, fanless operation, and rack/wall mountable options make it a versatile choice for both traditional and edge deployments.
| Specification | Details |
|---|---|
| Product Series | GS980MX |
| Model Number | GS980MX/18HSM |
| Manufacturer Part Number | AT-GS980MX/18HSM-10 |
| Switch Type | Layer 3 Managed |
| Total Network Ports | 16 x 5GBase-T PoE++ (up to 90W per port) |
| Expansion Slots | 2 x 10G SFP+ |
| Stacking Support | Yes (VCStack™) |
| Modular Design | Yes |
| PoE Standard | IEEE 802.3af/at/bt |
| Total PoE Budget | 720W |
| Max Power Consumption | 86W |
| Ethernet Standards | 5GBase-T, 10GBase-X |
| Media Support | Twisted Pair, Optical Fiber |
| Mounting Options | Rack-mountable, Wall-mountable |
| Dimensions (HxWxD) | 1.7" x 17.4" x 10.1" |
| Weight | 9.48 lbs (Shipping weight: 13 lbs) |
| Environment | Industrial, Enterprise |
| Manageable | Yes |
| Power Supply | 1 Installed |
| Environmental Compliance | Yes |
| Condition | New and Factory Fresh |
