Description
The Allied Telesis x530DP-52GHXM is a high-performance, stackable Layer 3 switch designed for modern enterprise networks. It features 48 PoE++ network ports (40 x 1G + 8 x 5G), 4 x 10G SFP+ uplink slots, and a robust 1480W PoE budget, making it ideal for high-density deployments, IP surveillance, and wireless AP connectivity.
With Vista Manager™ EX and Autonomous Management Framework™ (AMF), network operations are simplified via powerful automation and visualization tools. Resiliency features like EPSRing™, VCStack™, and Long Distance Stacking ensure high availability, while compliance with numerous IEEE standards provides flexible interoperability.
Whether deployed at the distribution layer or as a core switch for SMBs and enterprises, the x530DP-52GHXM delivers unmatched scalability, performance, and energy efficiency.
| Specification | Details |
|---|---|
| Product Model | x530DP-52GHXM |
| Part Number | AT-X530DP-52GHXM |
| Product Type | Layer 3 Stackable Switch |
| Total Network Ports | 48 (40 x 1G PoE++, 8 x 5G PoE++) |
| Uplink Ports | 4 x 10G SFP+ Slots |
| Media Support | Optical Fiber, Twisted Pair |
| Ethernet Standards | 10/100/1000Base-T, 5GBase-T, 10GBase-X |
| Expansion Slots | 4 x SFP+ |
| PoE Budget | 1480W PoE++ |
| Power Consumption | 150W |
| Management Features | AMF, Vista Manager EX, Device GUI, CLI, SNMP |
| Stacking Capability | VCStack™ up to 8 units, VCStack LD over fiber |
| Layer Support | Layer 3 |
| Network Standards Compliance | IEEE 802.3, 802.3at, 802.3bt, 802.1Q, 802.1x, etc. |
| Form Factor | Rack-mountable (19") |
| Dimensions (HxWxD) | 1.7" x 17.4" x 16.6" |
| Weight | 12.35 lbs (5.6 kg) |
| PoE Support | Yes (RJ-45) |
| Environmentally Friendly | Yes (RoHS Compliant) |
| Included Accessories | Rack-mount brackets |
| Product Condition | New and Factory Fresh |
| Shipping Weight | 18 lbs |
