Description
The Lenovo ThinkSystem SR630 V2 7Z71A05HNA is a high-performance, 1U rack server engineered for modern enterprise workloads, from virtualization and cloud computing to database management, collaboration platforms, and high-performance computing (HPC). Powered by the Intel Xeon Silver 4309Y 2.80 GHz processor and built on the Intel C621A chipset, this dual-socket server combines outstanding compute power with exceptional scalability and reliability.
With support for up to 8 TB of TruDDR4 ECC memory and Intel Optane Memory, the SR630 V2 ensures seamless scalability for future growth. Advanced storage options with support for 0, 1, 5, 10, and JBOD RAID levels, combined with Intel RSTe RAID controller, deliver superior data integrity and performance. Enterprise-grade features such as XClarity Controller (XCC) Enterprise remote management, integrated Matrox G200 graphics, and Gigabit Ethernet connectivity make deployment, monitoring, and maintenance efficient and secure.
Designed for flexibility and efficiency, the SR630 V2 is an excellent choice for businesses that demand powerful performance, energy efficiency, and enterprise-level reliability in a compact 1U form factor.
| Specification | Details |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Part Number | 7Z71A05HNA |
| Product Line | ThinkSystem |
| Series / Model | SR630 V2 |
| Form Factor | 1U Rack Server |
| Processor | 1 x Intel Xeon Silver 4309Y 2.80 GHz (Octa-core, 8 Core) |
| Processors Supported / Installed | 2 Supported / 1 Installed |
| Chipset | Intel C621A |
| Cache | 12 MB |
| Memory Installed / Max Supported | 32 GB / Up to 8 TB |
| Memory Technology | TruDDR4 ECC Registered (Buffered), 3.20 GHz |
| Memory Slots (Total / Occupied) | 32 / 1 |
| Intel Optane Memory Ready | Yes |
| RAID Controller | Intel RSTe RAID |
| Supported RAID Levels | 0, 1, 5, 10, JBOD |
| Storage Options | Supports Serial ATA/600 and 12Gb/s SAS |
| Graphics | Matrox G200, 16 MB |
| Ethernet | Gigabit Ethernet |
| Ports | 6 x USB, 1 x VGA, 1 x RJ-45 |
| Remote Management | XClarity Controller (XCC) Enterprise |
| Operating Systems Supported | Windows Server 2016/2019/2022, RHEL 7.9/8.2/8.3/8.4/8.5, SUSE Linux Enterprise Server 12 SP5, 15 SP2/SP3 |
| Power Supply | 1 x 750 W (Hot Swappable, C13/C14) |
| Power Supplies Supported / Installed | 2 Supported / 1 Installed |
| Input Voltage | 120 V AC / 230 V AC |
| Physical Dimensions (H x W x D) | 1.7" x 17.3" x 30.4" |
| Weight | 57.98 lb |
| Security | TPM 2.0, Chassis Intrusion Switch, Admin Password, Power-on Password |
| Environmental Certifications | ENERGY STAR 3.0, RoHS, EPEAT Bronze, CELP, GREENGUARD, CECP |
| Warranty | 3-Year Limited Warranty |
| Additional Features | Intel Optane Memory Ready, JBOD Support, Remote Management Ready |
