Description
The Lenovo ThinkSystem SR630 V2 7Z71A05KNA is a high-performance, 2-socket 1U rack server built to deliver enterprise-class reliability, scalability, and security in a compact design. Powered by a 3rd Gen Intel® Xeon® Silver 4309Y 8-core processor and equipped with 64 GB of TruDDR4 ECC memory, this server is engineered to handle demanding workloads such as virtualization, cloud computing, database management, VDI, and enterprise applications.
With support for dual processors, up to 8 hot-swappable SFF bays, and a 480 GB SSD for fast data access, the SR630 V2 ensures future-proof scalability and superior data throughput. It features 25 GbE network connectivity, Matrox G200 graphics, and Lenovo’s XClarity Controller (XCC) for advanced remote management. Designed with redundant 1100 W power supplies and Intel® Optane™ Memory readiness, this server offers exceptional uptime and operational efficiency, making it an ideal choice for modern data centers and enterprise environments.
| Category | Specification |
|---|---|
| General | |
| Manufacturer | Lenovo Group Limited |
| Product Line | ThinkSystem |
| Series | SR630 V2 |
| Model | 7Z71A05KNA |
| Form Factor | 1U Rack Server |
| Product Type | Server |
| Processor | |
| Processor Manufacturer | Intel |
| Processor Type | Xeon Silver |
| Processor Generation | 3rd Gen |
| Processor Model | 4309Y |
| Processor Core Count | 8 Cores (Octa-core) |
| Processor Speed | 2.80 GHz |
| Cache | 12 MB |
| Number of Processors Installed | 1 |
| Number of Processors Supported | 2 |
| Chipset | Intel C621A |
| Memory | |
| Installed Memory | 64 GB TruDDR4 ECC |
| Memory Speed | 3200 MHz |
| Total Memory Slots | 32 |
| Occupied Memory Slots | 2 |
| Intel Optane Memory Ready | Yes |
| Storage | |
| SSD Capacity | 480 GB |
| Storage Interface | Serial ATA/600, 12Gb/s SAS |
| RAID Support | Yes |
| Controller Model | 9350-8i |
| Expansion & Bays | |
| Total Expansion Bays | 8 |
| Internal 2.5" Bays | 8 |
| SFF Bays | 8 |
| Hot Swappable Bays | Yes |
| Expansion Slots | 4 |
| Graphics | |
| Graphics Controller | Matrox G200 |
| Graphics Memory | 16 MB |
| Networking | |
| Ethernet Technology | 25 Gigabit Ethernet |
| Network Ports (RJ-45) | 2 |
| I/O Interfaces | |
| Total USB Ports | 6 |
| USB 2.0 Ports | 1 |
| VGA Ports | 1 |
| Remote Management | XClarity Controller (XCC) |
| Operating System Support | |
| Supported OS | Windows Server 2016/2019, Red Hat Enterprise Linux 7.9/8.2/8.3, SUSE Linux Enterprise Server 12 SP5/15 SP2 |
| Power & Cooling | |
| Power Supply | 2 × 1100 W (Redundant, Hot-swappable) |
| Input Voltage | 120 V AC / 230 V AC |
| Connector Type | C13/C14 |
| Physical Characteristics | |
| Dimensions (H × W × D) | 1.7" × 17.3" × 30.4" |
| Weight | 57.98 lb |
| Rack Height | 1U |
| Security & Compliance | |
| Security Features | Chassis Intrusion Switch, Power-on Password, Administrator Password, TPM 2.0 |
| Environmental Certifications | ENERGY STAR 3.0, RoHS, EPEAT Bronze, CELP, GREENGUARD, CECP |
| Warranty | |
| Limited Warranty | 3 Years |
