Description
The Lenovo ThinkSystem SR665 7D2V1006NA is a high-performance, dual-socket 2U rack server designed to deliver powerful compute, scalability, and flexibility for modern data centers. Powered by a 3rd Gen AMD EPYC 7643 48-core processor and support for up to 8 TB TruDDR4 memory, this server is ideal for demanding workloads such as virtualization, databases, high-performance computing (HPC), and cloud infrastructure.
With PCIe Gen4 support, a versatile 16-bay SFF hot-swappable storage, and redundant 1100 W power supplies, the SR665 offers industry-leading I/O bandwidth and exceptional uptime. Enhanced by integrated XClarity Controller (XCC) Enterprise remote management, robust security features including TPM 2.0 and secure boot, and broad OS compatibility, it ensures reliable and secure operation in mission-critical environments.
Whether you’re scaling your infrastructure or optimizing performance-intensive applications, the ThinkSystem SR665 provides enterprise-grade performance, energy efficiency, and future-ready expansion in a compact 2U design.
| Category | Specification |
|---|---|
| General Information | |
| Manufacturer | Lenovo Group Limited |
| Part Number | 7D2V1006NA |
| Product Line | ThinkSystem |
| Product Series | SR665 |
| Product Model | 7D2V1006NA |
| Form Factor | 2U Rack Server |
| Product Type | Server |
| Processor | |
| Processor Type | AMD EPYC |
| Processor Generation | 3rd Gen “Milan” |
| Processor Model | 7643 |
| Processor Core Count | 48 Cores |
| Processor Speed | 2.30 GHz |
| Cache | 256 MB |
| Number of Processors Supported | 2 |
| Number of Processors Installed | 1 |
| Memory | |
| Standard Memory | 32 GB TruDDR4 |
| Maximum Memory Supported | 8 TB |
| Memory Clock Speed | 3200 MHz |
| Memory Slots (Total/Used) | 32 / 1 |
| Memory Type | Registered ECC DDR4 |
| Storage | |
| Total SSD Capacity | 1.92 TB |
| SSD Configuration | 1 x 1.92 TB SSD |
| SSD Interface | Serial ATA/600 |
| RAID Support | Yes |
| Controller | |
| Controller Type | Serial ATA / 12Gb/s SAS |
| Controller Model | 930-16i |
| Expansion & I/O | |
| Total Expansion Bays | 16 x 2.5" SFF Hot-Swappable Bays |
| PCIe Expansion Slots | 3 (x16, x8, x8) PCIe Gen4 |
| Total USB Ports | 6 (1 x USB 2.0, 5 x USB 3.1 Type-A) |
| VGA Ports | 2 |
| Remote Management | XClarity Controller (XCC) Enterprise |
| Graphics | |
| Graphics Controller | Matrox G200 |
| Graphics Memory | 16 MB |
| Networking | |
| Ethernet Technology | Gigabit Ethernet |
| Network Ports | RJ-45 |
| Power | |
| Power Supplies | 2 x 1100 W Hot-Swappable Redundant PSU |
| Input Voltage | 120V AC / 230V AC |
| Connector Type | C13 |
| Physical Characteristics | |
| Dimensions (H x W x D) | 3.4" x 17.5" x 30.1" |
| Weight | 85.54 lb |
| Operating System Support | Windows Server 2016/2019/2022, Red Hat Enterprise Linux 7.6–9.2, SUSE Linux Enterprise Server 12 SP5–15 SP5, Ubuntu 22.04 LTS x64 |
| Security & Compliance | |
| Security Features | Secure Boot, Firmware Signature (FIPS/NIST), TPM 2.0 |
| Certifications | ENERGY STAR 3.0, RoHS |
| Warranty | |
| Limited Warranty | 3 Years (CRU and Onsite with 9x5 NBD) |
