Description
The Vertiv Liebert ITA2-BCI0020K02 External Battery Cabinet (EBC) System is engineered for scalability and high performance in mission-critical environments. Designed to support the Liebert ITA2 3-phase UPS systems (ITA2-08KRT208C and ITA2-10KRT208C), this EBC provides extended runtime with two 2U cabinets per string (4U total). With user-replaceable valve-regulated lead-acid batteries, this hot-swappable solution ensures uninterrupted power during maintenance or expansion.
Ideal for rack or tower installations, the ITA2-BCI0020K02 offers reliable DC output of 384V and features integrated hardware kits, quick start guide, and support for additional cabinets in parallel for future runtime expansion. A 2-year standard warranty is included, with optional 1- and 3-year extensions.
| Feature | Details |
|---|---|
| Brand | Vertiv Liebert |
| Model | ITA2-BCI0020K02 |
| Series | ITA2 |
| Product Type | External Battery Cabinet (EBC) |
| Mount Type | Rackmount / Tower |
| Rack Height | 4U (2 x 2U Cabinets) |
| Input / Output Voltage | 384V DC |
| Battery Chemistry | Valve-Regulated Lead Acid (VRLA), User Replaceable |
| Hot Swappable | Yes |
| No. of Batteries | 16 per cabinet (32 per string) |
| Compatibility | ITA2-08KRT208C, ITA2-10KRT208C |
| Weight | Approx. 230 lbs |
| Dimensions (H x W x D) | 3.3" x 16.9" x 29.6" |
| Operating Temperature | 32°F to 122°F (0°C to 50°C), Optimal: 77°F (25°C) |
| Protection Types | Undervoltage, Overtemp, Overvoltage, Overcurrent, Short Circuit, No Load |
| Warranty | 2 Years (1 & 3-year extension optional) |
| Certifications | UL 1778, CSA 22.2 No. 107.3, CE, ISTA 3B |
| Environmental Compliance | REACH, RoHS 2, WEEE |
| Shipping Weight | 1 lb (as per label; may vary with full set contents) |
| Package Contents | 2x Battery Cabinets, Rack Rails, Hardware, Support Bases, Guide |
