Description
The Shure Microflex Advance MXA710 2-Foot Linear Array Microphone delivers premium audio capture for modern AV conferencing environments, combining sleek industrial design with advanced signal processing. Its linear form factor allows flexible placement on walls, ceilings, tables, or around displays, making it ideal for boardrooms, meeting spaces, and collaboration areas.
Equipped with Shure’s Steerable Coverage™ technology, the MXA710 dynamically captures voices across the room using multiple configurable lobes, while Autofocus™ technology continuously refines coverage in real time as participants move. Integrated IntelliMix® DSP ensures crystal-clear audio with built-in acoustic echo cancellation, noise reduction, automatic gain control, and mixing.
Designed for seamless integration into enterprise AV ecosystems, the MXA710 supports Dante and AES67 digital audio networking, is powered via PoE for simplified installation, and is fully configurable through Shure Designer software. Its low-profile design and configurable LED status bar allow it to blend effortlessly into any professional environment while delivering consistent, high-performance audio.
| Specification | Details |
|---|---|
| Form Factor | 2-foot linear array microphone |
| Color | Black |
| Microphone Type | Linear array (MEMS-based) |
| Microphone Elements | 50 MEMS microphones |
| Frequency Response | 100 Hz to 20 kHz |
| Maximum SPL | 101.4 dB SPL |
| Signal-to-Noise Ratio | 71.2 dB (A-weighted) |
| Dynamic Range | 78.5 dB |
| Sensitivity | -7.4 dBFS/Pa at 1 kHz |
| Coverage Technology | Steerable Coverage with up to 4 lobes |
| Autofocus Technology | Real-time automatic lobe adjustment |
| DSP Features | Acoustic Echo Cancellation, Noise Reduction, Automatic Gain Control, Compressor, Delay, Parametric EQ, Automixing |
| Digital Audio Networking | Dante and AES67 compatible |
| Channels | 6 total (4 direct outputs, 1 automix, 1 AEC reference) |
| Sampling Rate | 48 kHz |
| Bit Depth | 24-bit |
| Connectivity | RJ45 Ethernet |
| Power Requirements | Power over Ethernet (PoE), Class 0 |
| Power Consumption | 10W maximum |
| Mounting Options | Wall, ceiling, table, display mount, suspension, VESA-compatible accessories |
| Dimensions (H x W x L) | 0.87 x 2.36 x 25.04 inches |
| Weight | 2 lbs (0.91 kg) |
| Operating Temperature | 20°F to 104°F (-6.7°C to 40°C) |
| Network Control | Shure Designer software |
| LED Indicators | Configurable status LED bar |
| Security | AES-256 audio encryption support |
