Description
The AddOn SFP-10GB-DW20-H-80-AO is a high-performance, MSA-compliant 10GBase-DWDM SFP+ transceiver designed to deliver reliable optical connectivity up to 80 km over single-mode fiber (SMF). Operating on the ITU-T C-Band with a 100 GHz channel spacing and a 1561.42 nm wavelength, this transceiver is ideal for metro, access, and enterprise DWDM applications.
Equipped with a cooled EML transmitter and APD receiver, it supports data rates from 9.95 Gbps to 11.3 Gbps and offers digital optical monitoring (DOM) for real-time performance insights. The module operates over an extended industrial temperature range from -40 °C to +92 °C, ensuring consistent performance in demanding environments. TAA compliant and fully hot-pluggable, this transceiver provides a cost-effective, high-reliability solution for expanding network capacity while maintaining seamless interoperability.
| Specification | Details |
|---|---|
| Compatible OEM | Industry Standard |
| Data Rate | 9.95 Gbps – 11.3 Gbps |
| Form Factor | SFP+ |
| Transmission Standard | 10GBase-DWDM |
| Wavelength | 1561.42 nm (C-Band, 100 GHz) |
| Connector | LC Duplex |
| Media | Single-Mode Fiber (SMF) |
| Maximum Reach | 80 km |
| Optical Transmitter | Cooled EML with TEC |
| Receiver Type | APD |
| Digital Optical Monitoring (DOM) | Supported |
| Average Optical Power | 0 dBm to +5 dBm |
| Receiver Sensitivity | -23 dBm |
| Receiver Overload | -8 dBm |
| Extinction Ratio | ≥ 9 dB |
| Power Consumption | < 2.8 W |
| Power Supply Voltage | 3.3 V |
| Operating Temperature | -40 °C to +92 °C |
| Compliance | MSA, TAA, SFF-8431/8432, RoHS-6, FCC, EN55022, IEC 60825-1/2 |
| Applications | 10G Ethernet over DWDM, 8G/10G Fibre Channel, Metro/Access/Enterprise Networks |
| Hot-Pluggable | Yes |
| Warranty | Limited Lifetime Warranty |
