Description
The Advantech MIC-710AIX-00A1 is a compact, fanless AI inference system powered by the NVIDIA Jetson Xavier NX platform, delivering up to 21 TOPS of edge AI performance. Designed for industrial-grade deployment, it supports robust I/O connectivity including dual Gigabit Ethernet, HDMI display output, USB expansion, and digital I/O channels for automation integration.
With onboard eMMC storage, expandable M.2 SATA support, and Allxon remote monitoring with OTA deployment capabilities, the MIC-710AIX is ideal for smart manufacturing, machine vision, robotics, and real-time AI analytics at the edge.
| Specification Category | Details |
|---|---|
| Brand | Advantech |
| Model | MIC-710AIX |
| SKU | MIC-710AIX-00A1 |
| AI Platform | NVIDIA Jetson Xavier NX |
| AI Performance | Up to 21 TOPS |
| CPU | 6-core NVIDIA Carmel ARM v8.2 64-bit |
| GPU | 384-core NVIDIA Volta GPU with 48 Tensor Cores |
| Memory | 8GB LPDDR4 |
| Flash Storage | 16GB eMMC |
| Ethernet Ports | 2 × Gigabit Ethernet (10/100/1000 Mbps) |
| USB Ports | 1 × USB 3.0, 2 × USB 2.0 (internal/external) |
| Display Output | HDMI (Max 3840 × 2160 @ 60Hz) |
| Digital I/O | 4-ch DI, 4-ch DO |
| Serial Ports | 1 × RS-232 (internal), 1 × RS-232/422/485 (external) |
| Expansion Slots | 1 × Mini PCIe, 1 × M.2 2280 (SATA) |
| SIM Support | 1 × Nano SIM Slot |
| Storage Expansion | Micro SD Slot, SATA3 connector, M.2 SATA3 |
| Power Input | 19–24 VDC Terminal Block |
| Operating Temperature | -10°C to +60°C (with airflow) |
| Mounting Options | Desktop / DIN-Rail |
| Dimensions (W×D×H) | 147 × 118 × 52 mm |
| Weight | Approx. 1.2 kg |
| Certifications | CE / FCC / BSMI / CCC |
| Remote Management | Allxon OTA + Azure Certified Device |
