Description
The Opengear CM8148-DDC Console Manager is a high-density, next-generation solution designed for secure, reliable, and automated out-of-band management. Featuring 48 straight-pinout serial ports and dual DC power inputs, it ensures continuous connectivity for mission-critical environments. Equipped with a 1.6GHz dual-core ARM processor, 2GB DDR4 memory, and 32GB onboard flash storage, the CM8148-DDC delivers robust performance with advanced automation capabilities.
With built-in support for Docker, Python, and API integration, it simplifies data center automation while enhancing security through Trusted Platform Module (TPM) 2.0, embedded firewall, and VPN support. Ideal for replacing legacy terminal servers, the CM8148-DDC ensures resilient management with passive cooling, IPv6 compatibility, and multi-layer authentication.
| Category | Details |
|---|---|
| Model / SKU | CM8148-DDC |
| Form Factor | 1RU Rackmount |
| Serial Ports | 48 x RJ45 RS-232 (Cisco straight X2 pinout), 50–230,400 bps |
| Network Ports | 2 x 10/100/1000 Ethernet, 1500V AC isolation, ESD protection |
| Console Port | 1 x RJ45 RS-232 (Cisco rolled X1 pinout, 9600 baud) |
| USB Ports | 2 x USB 3.0 host (external storage or device management) |
| CPU | 1.6GHz Dual-Core ARM Cortex-A9 SoC |
| Memory | 2GB DDR4 SDRAM |
| Storage | 32GB eMMC flash |
| Security | TPM 2.0, AAA (TACACS+, RADIUS, AD/LDAP), Embedded Firewall, IPSec & OpenVPN |
| Automation | API, Python, Perl, Bash, Docker, ZTP, SNMP (standard MIBs) |
| Power Supply | Dual DC: ±40V to 72V DC |
| Power Consumption | < 15W (51 BTU/h) typical |
| Cooling | Passive (forward/reverse mounting supported) |
| Dimensions | 17.3" x 9.25" x 1.75" (440 x 235 x 44 mm) |
| Weight | 9.5 lbs (4.5 kg) |
| Operating Temp. | 5°C to 50°C (41°F to 122°F) |
| Storage Temp. | -30°C to +60°C (-22°F to 140°F) |
| Humidity | 5%–90% non-condensing |
| Certifications | FCC, CE, VCCI, RoHS, IEC 60950, IEC 62368, EN/IEC standards |
| MTBF | 150,000 hours |
| Warranty | 5 years hardware replacement (with Foundation Support subscription) |
