Description
The Opengear CM8132-DDC is a high-density, rackmount console manager designed for secure, reliable, and scalable out-of-band management in enterprise and data center environments. With 32 straight-pinout serial ports, dual Gigabit Ethernet interfaces, and Dual DC power inputs, it delivers redundancy and resilience for mission-critical networks.
Powered by a 1.6GHz dual-core ARM Cortex-A9 CPU, 2GB DDR4 memory, and 32GB eMMC storage, this model supports Docker, Python, and Zero Touch Provisioning (ZTP), enabling automation and rapid deployment. Embedded security features include a Trusted Platform Module (TPM) 2.0, IPSec, and OpenVPN for secure access.
Designed in a 1RU rackmount form factor, the CM8132-DDC provides centralized, remote access to console ports with an intuitive web UI, SSH, and SNMP support. It is ideal for replacing legacy terminal servers and ensuring continuous network uptime with proactive monitoring, automatic failover, and smart out-of-band management.
| Category | Details |
|---|---|
| Model | Opengear CM8132-DDC |
| Form Factor | 1RU Rackmount |
| Serial Ports | 32 x RJ45 RS-232 (Cisco straight X2 pinout, 50–230,400bps) |
| Network Ports | 2 x 10/100/1000 Ethernet (with 1500V AC isolation & ESD protection) |
| Console Port | 1 x RJ45 RS-232 Console Port (Cisco rolled X1 pinout, 9600 baud) |
| USB Ports | 2 x USB 3.0 host ports (external storage or device console management) |
| CPU | 1.6GHz Dual-Core ARM Cortex-A9 SoC (Marvell 88F6820) |
| Memory | 2GB DDR4 SDRAM |
| Storage | 32GB eMMC |
| Security | TPM 2.0, AAA (TACACS+, RADIUS, AD/LDAP), IPSec, OpenVPN, embedded firewall |
| Automation & Management | Docker, Python, Perl, Bash, API access, ZTP, SNMP (standard MIBs) |
| Power Supply | Dual DC: ±40V to 72V DC |
| Power Consumption | < 15W (51 BTU/h typical) |
| Cooling | Passive (forward or reverse mount) |
| Dimensions | 17.3” x 9.25” x 1.75” (440 x 235 x 44 mm) |
| Weight | 9.5 lbs (4.5 kg) |
| Operating Temp | 5°C to 50°C (41°F to 122°F) |
| Storage Temp | -30°C to +60°C (-22°F to 140°F) |
| Humidity | 5%–90% non-condensing |
| Certifications | FCC, CE, RoHS, VCCI, EN/IEC standards |
| Warranty | 5-year hardware replacement (with Foundation Support purchase required) |
