Description
The Ortronics Mighty Mo 20 4-Post Fixed Rack (MM20730FXD12-B) provides a high-density, durable mounting platform designed for switches, servers, and other networking equipment. Featuring patented channel construction and honeycomb side rails, this rack maximizes airflow while protecting cabling performance.
Its open top and bottom channels simplify cable routing from both floor and ceiling, while the built-in top trough and waterfalls ensure proper bend radius control. The rack’s modular design allows assembly as either a 19" or 23" rack—without the need for additional hardware.
The Mighty Mo 20 4-Post Rack comes complete with mounting hardware, hook-and-loop D-style straps, and #12-24 equipment screws, delivering a cost-effective, ready-to-install solution for data centers and commercial network environments.
| Category | Specification |
|---|---|
| Brand | Ortronics |
| Product Line | Mighty Mo 20 |
| Type | 4-Post Fixed Rack |
| Part Number / SKU | MM20730FXD12-B |
| Rack Units | 45 RU |
| Mounting Rail Spacing | 19 in (configurable to 23 in) |
| Mounting Hole Type | Tapped |
| Rack Depth | 30 in |
| Product Width (US) | 23.75 in |
| Product Height (US) | 86.0 in |
| Product Depth (US) | 40.0 in |
| Product Weight (US) | 52.93 lb |
| Load Capacity | 2000 lb |
| Cable Entry | Front and Rear |
| Frame Type | Fixed |
| Mounting Method | Floor Mount |
| Color / Finish | Black / Powder Coat |
| Material Features | Patented honeycomb side rails, built-in top trough with waterfalls, vertical cable management compatibility |
| Compatibility | Mighty Mo series accessories and vertical managers |
| Certifications / Standards | UL 2416 |
| Compliance | RoHS Compliant |
| Country of Origin | United States |
| Warranty | 5-Year Limited Warranty |
| Included Hardware | Mounting hardware, two hook-and-loop D-style strap packs, fifty #12-24 screws |
