Description
The Mimo Monitors MOD-10180H is a compact, high-brightness 10.1-inch outdoor commercial display engineered for reliable performance in demanding environments. Featuring a WXGA (1280 x 800) resolution and 1000-nit brightness, this monitor ensures clear visibility even in bright ambient lighting conditions, making it ideal for outdoor digital signage, kiosks, and point-of-sale installations.
Built with a rugged all-aluminum enclosure, the MOD-10180H is IP65-rated to withstand dust, water, humidity, and other environmental elements. Its IK10-rated impact-resistant design adds protection against vandalism, ensuring durability in public and high-traffic locations. The display also incorporates a built-in ambient light sensor to automatically adjust brightness for optimal viewing throughout the day.
Designed for continuous operation, this monitor supports 24/7 usage and operates in extreme temperatures ranging from -20°F to 140°F. With flexible mounting options and support for both landscape and portrait orientations, the MOD-10180H delivers dependable performance for commercial outdoor applications such as quick-service restaurants, transportation hubs, amusement parks, and gas stations.
| Specification | Details |
|---|---|
| Display Size | 10.1 inches |
| Native Resolution | 1280 x 800 (WXGA) |
| Aspect Ratio | 16:10 |
| Panel Type | LCD |
| Brightness | 1000 nits |
| Contrast Ratio | 800:1 |
| Viewing Angles | 176° (H) / 176° (V) |
| Refresh Rate | 60 Hz |
| Screen Finish | Anti-glare (3H cover glass) |
| Touch Capability | Non-touch display |
| Display Orientation | Landscape and Portrait |
| A/V Input | 1 x HDMI |
| A/V Output | 1 x 3.5 mm audio |
| USB Connectivity | Not supported |
| Ethernet Connectivity | Not supported |
| HDCP Support | Not supported |
| Ambient Light Sensor | Yes |
| Built-In Speakers | Not included |
| Built-In Microphone | Not included |
| Power Consumption | 40W (operational) |
| Input Power | 100 to 240 VAC, 50/60 Hz |
| Power Supply | External adapter |
| Operating Temperature | -20°F to 140°F (-28°C to 60°C) |
| Environmental Protection | IP65-rated (dust, water, humidity resistant) |
| Impact Resistance | IK10-rated vandal resistance |
| Housing Material | All-aluminum enclosure |
| Mounting Pattern | VESA 100 x 100 mm |
| Duty Cycle | 24/7 continuous operation |
| Certifications | CE, FCC, RoHS |
| Included Accessories | Power supply, remote control |
