Description
The AddOn Palo Alto Networks® PAN-QSFP28-100GBASE-IR4 Compatible TAA 100GBase-IR4 QSFP28 Transceiver is designed to deliver high-performance, reliable 100GbE connectivity for enterprise and data center applications. Supporting data transmission up to 2km over single-mode fiber (SMF) using a 1310nm wavelength and duplex LC connector, this transceiver ensures seamless network integration and exceptional throughput.
Each unit is programmed, uniquely serialized, and rigorously application-tested to guarantee 100% compatibility with Palo Alto Networks® hardware. With Digital Optical Monitoring (DOM) support, network operators gain real-time visibility into key operating parameters. The module is hot-swappable, RoHS compliant, TAA compliant, and offers excellent EMI and ESD protection, making it a dependable solution for high-speed optical networking environments.
Backed by AddOn’s limited lifetime warranty, this transceiver combines OEM-level quality with cost efficiency, ensuring maximum uptime and seamless scalability.
| Specification | Description |
|---|---|
| Compatible OEM | Palo Alto Networks® |
| Model / SKU | PAN-QSFP28-100GBASE-IR4-AO |
| Form Factor | QSFP28 |
| Data Rate per Channel | 25.78125 Gb/s |
| Aggregate Data Rate | 100GBase-IR4 |
| Wavelength | 1310nm |
| Reach / Distance | Up to 2km |
| Fiber Type | Single-Mode Fiber (SMF) |
| Connector Type | Duplex LC |
| Digital Optical Monitoring (DOM) | Supported |
| Hot Swappable | Yes |
| Operating Temperature | 0°C to 70°C |
| Storage Temperature | -40°C to +85°C |
| Power Supply Voltage | 3.135V – 3.465V |
| Power Dissipation | 3.5W (max) |
| Module Supply Current | 1100 mA |
| Transmitter Launch Power (per lane) | -6.5 to 2.5 dBm |
| Receiver Sensitivity (per channel) | ≤ -11.5 dBm |
| Extinction Ratio | ≥ 4 dB |
| Compliance | SFF-8665, FCC Part 15 Subpart B, EN55022:2010, FDA 21CFR, EN60950-1, IEC 60825-1/2 |
| ESD Protection | MIL-STD-883E Method 3015.4 |
| EMI Shielding | Metal housing with low EMI |
| RoHS / TAA Compliant | Yes / Yes |
| Warranty | Limited Lifetime Warranty |
