Description
The Perle IDS-509G3PP6-T2MD05-SD120 is a rugged industrial-grade managed PoE+ Ethernet switch engineered for mission-critical applications in harsh environments. Featuring 9 ports—including six 10/100/1000Base-T RJ45 PoE/PoE+ capable ports, two 1000Base-SX multimode ST fiber ports, and one 1000Base-ZX single-mode ST fiber port—it ensures maximum flexibility and secure data transmission over both copper and fiber.
Designed as Power Sourcing Equipment (PSE), this switch delivers up to 30W per port for powering access points, IP phones, and cameras directly over Ethernet. Its PRO feature set includes advanced security, AAA authentication, VLANs, ACLs, SNMPv3, IEEE 802.1x, and QoS to meet demanding enterprise and industrial networking requirements.
With robust aluminum construction, -10°C to 60°C operating range (up to -40°C to 75°C for XT models), redundant dual power inputs, and immunity to electromagnetic interference, the IDS-509GPP6 is ideal for industries such as oil & gas, utilities, military, mining, and transportation.
Engineered for real-time deterministic network performance, it supports protocols like MSTP, GMRP, LLDP, IGMP/MLD Snooping, and Perle’s P-Ring redundancy. A fanless design ensures durability and low maintenance in demanding field installations.
| Category | Details |
|---|---|
| Manufacturer | Perle Systems |
| SKU / Part Number | 07017020 |
| Model | IDS-509G3PP6-T2MD05-SD120 |
| Port Configuration | (6) 10/100/1000Base-T RJ45 (PoE/PoE+), (2) 1000Base-SX multimode ST (850nm, up to 550m), (1) 1000Base-ZX single-mode ST (1550nm, up to 120km) |
| PoE Capability | IEEE 802.3af/at compliant, up to 30W per port |
| Switching Features | VLAN, QoS, IGMP Snooping, MLD Snooping, MSTP, GMRP, Voice VLANs, LLDP, GVRP |
| Security | RADIUS, TACACS+, IEEE 802.1x, SSH, HTTPS, SNMPv3, Management ACLs |
| Management Interfaces | CLI (Telnet/Serial), Web GUI, SNMP, RMON |
| Redundancy | Dual power input (48 VDC), reverse polarity, overload protection |
| Construction | Corrosion-resistant aluminum case, DIN rail mount |
| Operating Temperature | Standard: -10°C to 60°C; XT Models: -40°C to 75°C |
| Certifications | Hazardous Location, Programmable Controller safety approvals |
| Form Factor | Fanless, industrial DIN-rail mount design |
| Advanced Functions | P-Ring resiliency, N:1 port mirroring, digital inputs for alert generation |
