Description
The Hanwha Vision XNF-9010RS is a premium 12MP stainless steel fisheye camera engineered for demanding environments that require wide-area surveillance, durability, and advanced analytics. With its 1.08mm stereographic lens, the camera delivers exceptional clarity across the entire 360° field of view, ensuring crisp coverage from center to edge.
Designed for food processing, industrial, marine, and hygienic environments, the XNF-9010RS features a corrosion-resistant STS316L stainless housing, paired with extensive protection ratings including IP66, IP67, IP6K9K, IK10+, and NEMA 4X. Its hygienic certification under NSF/ANSI Standard 169 makes it ideal for safety-critical facilities.
Powered by Hanwha’s advanced video technologies such as extreme WDR (120dB), WiseStream II, digital PTZ, and multiple dewarping modes, the camera enables flexible monitoring whether in fisheye, single panorama, double panorama, or quad-view layouts. Built-in IR illumination (8m) ensures visibility even in complete darkness.
The camera also includes powerful AI-ready analytics, including people counting, heatmap, queue management, motion detection, tampering, and virtual line/area features. Dual microSD card slots support up to 1TB edge recording, while secure communication features provide protection through encrypted firmware, SRTP, HTTPS, and hardware-based TPM.
| Category | Specification |
|---|---|
| Image Sensor | 1/2.3" 12MP CMOS |
| Max Resolution | 3840×2160, 3584×2688, 3008×3008, 1920×960, 1504×1504, 1080×1080, others |
| Framerate | H.265/H.264: 30fps (60Hz), MJPEG: 30fps (@9MP max 5fps) |
| Min. Illumination | Color: 0.39 Lux (30IRE), B/W: 0.039 Lux |
| Lens | 1.08mm fixed, F2.2 stereographic lens |
| Field of View | 187° (H/V/D) |
| Dewarping Modes | Fisheye, Single Panorama, Double Panorama, Quad View |
| IR Illumination | WiseIR, 8m (26.25 ft), 850nm |
| Day/Night | Auto(ICR) |
| WDR | 120 dB Extreme WDR |
| Noise Reduction | SSNR V |
| Video Compression | H.265/H.264 (Main/Baseline/High), MJPEG |
| Smart Codec | WiseStream II |
| Audio | Built-in mic, Line in/out, G.711/G.726/AAC-LC |
| Analytics | Motion, Tampering, Defocus, Sound Classification, Virtual Line, Intrusion, Enter/Exit, People Counting, Queue Management, Heatmap |
| Alarm I/O | 2 configurable I/O ports |
| Network Protocols | IPv4/IPv6, TCP/IP, UDP/IP, RTP, RTSP, NTP, HTTP/HTTPS, SNMP, IGMP, SRTP, MQTT, ONVIF S/G/T |
| Security Features | Secure boot, encrypted firmware, AES-256 SD card encryption, HTPM (TPM module), IEEE 802.1X |
| Edge Storage | Dual SD slots: up to 512GB each (1TB total) |
| Operating Conditions | -40°C to +50°C, 0–95% RH |
| Ingress/Impact Rating | IP66 / IP67 / IP6K9K / IK10+ |
| Food Safety Rating | NSF/ANSI Standard 169 |
| Material | Stainless Steel STS316L, Nylon dome |
| Power | PoE (IEEE802.3af Class 3), 12VDC; Max 12.95W |
| Dimensions | Ø167.9 × 72.1 mm (6.61 × 2.84 in) |
| Weight | 2,980 g (6.57 lb) |
