Description
The iPGARD SDVN-16S-P is a high-security 16-port KVM switch engineered for environments where absolute data isolation and system integrity are critical. Designed for government, defense, financial, and enterprise control rooms, this secure KVM enables a single operator to control up to sixteen computers while maintaining strict separation between networks of varying classification levels.
Built with advanced anti-tampering mechanisms and certified to meet stringent security standards, the SDVN-16S-P eliminates the risk of data leakage between connected systems. Its dedicated CAC port allows secure integration of smart card and biometric authentication devices, ensuring controlled and compliant access across all connected machines.
With support for high-resolution DVI-I video up to 2560x1600 at 60Hz, USB keyboard and mouse emulation, and stereo audio switching, this KVM delivers both performance and protection. The unit maintains continuous emulation to prevent unauthorized peripheral detection while enabling fast, seamless switching between systems. Ideal for mission-critical operations, the SDVN-16S-P combines robust security architecture with reliable performance in a compact, rack-ready form factor.
| Category | Specification |
|---|---|
| Product Type | Secure KVM Switch |
| Ports | 16 Computer Ports |
| Console Support | Single-Head |
| Video Interface | DVI-I Dual Link |
| Max Resolution | Up to 2560 x 1600 @ 60Hz |
| Video Input | 16 x DVI-I (29-pin) |
| Video Output | 1 x DVI-I (29-pin) |
| Pixel Clock | 248 MHz |
| Data Rate | 1.65 Gbps |
| USB Input | 32 x USB Type-B |
| USB Output | 2 x USB Type-A for Keyboard and Mouse |
| USB Emulation | USB 1.1 and USB 2.0 Compatible |
| CAC Support | Dedicated Configurable USB 2.0 CAC Port |
| Audio Input | 16 x 3.5mm Stereo |
| Audio Output | 1 x 3.5mm Stereo |
| Switching Method | Front Panel Buttons with LED Indicators |
| Security Features | Non-reprogrammable ROM, Anti-tamper switches, Tamper-evident seals, Isolated channels |
| Isolation | Complete electrical, mechanical, and optical isolation |
| OS Compatibility | Windows, macOS, Linux |
| Power Supply | External 100–240VAC / 12VDC 3A |
| Power Consumption | 36W |
| Dimensions | 17.0” W x 2.7” H x 8.69” D |
| Weight | 6.9 lbs |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -20°C to 60°C |
| Humidity | Up to 80% non-condensing |
| Certifications | NIAP PP 3.0, UL, CE, RoHS |
