Description
The iPGARD SDHN-4Q-P Secure KVM Switch is engineered for high-security environments that require strict data isolation and uncompromised performance. Designed to control up to four computers from a single workstation, this quad-head KVM solution delivers seamless switching across multiple HDMI displays while maintaining absolute separation between connected systems.
Built to meet the latest Protection Profile 3.0 standards, this secure KVM incorporates advanced anti-tamper protections, non-reprogrammable ROM, and dedicated isolated channels to eliminate the risk of data leakage. Its integrated CAC (Common Access Card) port allows controlled authentication device switching, ensuring compliance with strict security protocols across defense, government, and enterprise deployments.
With support for 4K Ultra-HD resolution, keyboard and mouse emulation, and secure EDID learning, the SDHN-4Q-P ensures smooth, uninterrupted operation while protecting sensitive information. Whether deployed in command centers, financial institutions, or critical infrastructure, this KVM switch provides reliable, high-performance secure access across multiple systems.
| Specification Category | Details |
|---|---|
| Number of Ports | 4-Port Secure KVM |
| Display Support | Quad-head (4 displays) |
| Video Interface | DisplayPort input to HDMI output |
| Video Resolution | Up to 3840 x 2160 at 30Hz |
| Video Inputs | 16 DisplayPort inputs |
| Video Outputs | 4 HDMI outputs |
| USB Interface | USB Type-B (input), USB Type-A for keyboard and mouse |
| USB Compatibility | Supports USB 1.1 and USB 2.0 |
| CAC Port | Dedicated configurable USB 2.0 CAC port |
| Audio Support | 3.5mm stereo input and output |
| Switching Method | Front panel tactile buttons with LED indicators |
| Security Certification | NIAP Protection Profile 3.0 compliant |
| Security Features | Non-reprogrammable ROM, active anti-tamper protection, tamper-evident seals, isolated data channels |
| Data Isolation | Absolute isolation between ports to prevent data leakage |
| Emulation | Keyboard, mouse, and video emulation for continuous connectivity |
| EDID Management | Secure EDID learning and emulation |
| Operating Systems | Compatible with Windows, macOS, and Linux |
| Power Supply | External power adapter (100–240V AC to 12V DC) |
| Power Consumption | 36W |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -20°C to 60°C |
| Humidity | Up to 80% non-condensing |
| Dimensions | 12.57 in x 4.9 in x 6.69 in |
| Weight | 4.0 lbs |
| Compliance | UL, CE, RoHS compliant |
