Description
The Advantech PPC-415W-BTO-SRP is a high-performance 15.6-inch fanless widescreen industrial panel PC designed for demanding automation and HMI applications. Featuring a true-flat Full HD display with projected capacitive multi-touch, this rugged system combines reliability with modern computing power using Intel® 13th Gen Core™ processors.
Built for industrial environments, it supports rich I/O connectivity, dual 2.5GbE networking with TSN capability, PCIe/PCI expansion, TPM2.0 security, and wide-range DC input. The PPC-415W is ideal for factory automation, machine control, transportation, and smart manufacturing deployments.
| Specification | Details |
|---|---|
| Product Type | Industrial Fanless Panel PC |
| Model / SKU | PPC-415W-BTO-SRP |
| Display Size | 15.6" Widescreen TFT LCD |
| Resolution | 1920 × 1080 (Full HD) |
| Brightness | 450 cd/m² |
| Touchscreen | Projected Capacitive Multi-Touch (P-CAP) |
| Processor Options | Intel® Core™ i7/i5/i3 (13th Gen URE Series) |
| System Design | Fanless Cooling Architecture |
| Memory Support | DDR5 4800 MHz, up to 64GB (2× SODIMM) |
| Storage Support | 2.5" SATA Bay + M.2 NVMe/SATA Slot |
| Expansion Slots | PCIe x4 or Optional PCI |
| Network Ports | Dual 2.5GbE Intel I226LM with TSN Support |
| Serial Ports | 2× RS-232 + 1× Isolated RS-422/485 |
| USB Ports | 3× USB 3.2 + 1× USB 2.0 |
| Video Outputs | HDMI 1.4 + DisplayPort 1.4a |
| Security | TPM 2.0 Hardware Module |
| Mounting Support | Panel Mount + VESA 100 |
| Power Input | 9–32 VDC Wide Range |
| Operating Temperature | -20°C to 60°C |
| Front Panel Protection | IP66 Rated |
| Dimensions | 419.7 × 269 × 59 mm |
| Weight | Approx. 5.4 kg |
| OS Support | Windows 11, Windows 10 IoT LTSC, Linux |
