Description
The QNAP QGD-1602P-C3758-16G is the world’s first PoE-managed switch series that supports Virtual Machines (VMs) for next-level networking and application integration. Powered by an Intel® Atom® multi-core 2.2GHz processor and equipped with two SATA drive bays, it delivers exceptional performance for IP surveillance, network security, wireless AP management, and storage expansion.
With a combination of eight 2.5GbE PoE++ ports, four Gigabit PoE+ ports, and two 10GbE SFP+ uplink ports, the QGD-1602P ensures high-speed data transfer and powerful PoE delivery — up to 90W per port and 380W total budget — making it ideal for Wi-Fi 6 access points, routers, IP cameras, and other high-power devices.
Featuring Layer 2 management functions, PCIe expandability, M.2 SSD slots, and support for QNAP’s QuWAN SD-WAN solution, this switch provides small to medium-sized businesses with a secure, scalable, and performance-driven network infrastructure.
| Specification | Details |
|---|---|
| Brand | QNAP |
| Model | QGD-1602P-C3758-16G |
| Product Type | Managed PoE++ Ethernet Switch |
| Total Network Ports | 16 |
| Port Configuration | 4 × 2.5GbE PoE++ RJ-45, 4 × Gigabit PoE+ RJ-45, 2 × 10GbE SFP+ slots, 2 × 5GbE management ports, 2 × 1GbE management ports |
| PoE Standards | IEEE 802.3bt (PoE++), IEEE 802.3at (PoE+) |
| PoE Budget | 380W (4 × 90W, 12 × 30W) |
| Max Power Consumption | 280W |
| Networking Standards | IEEE 802.3u/ab/bz/an/ae/z/x/af/at/bt, IEEE 802.1Q/p |
| Layer Supported | Layer 2 |
| Media Type Supported | Optical Fiber, Twisted Pair |
| Expansion Slots | 2 × PCIe Gen3 x4, 2 × M.2 PCIe SSD |
| Form Factor | 1U Rack-Mountable |
| Dimensions (H × W × D) | 1.7" × 17.1" × 12.9" |
| Weight | 9.63 lb |
| Processor | Intel® Atom® multi-core 2.2GHz |
| Memory | 16GB DDR4 (Expandable) |
| Applications | IP Surveillance, Wireless AP Management, Network Security, SD-WAN, Storage Expansion |
| Warranty | 2-Year Limited Warranty |
