Description
The QNAP QSW-M3224-24T-US is a cost-effective Layer 3 Lite managed switch designed for high-performance enterprise networking. Featuring twenty-four 10GbE Multi-Gig RJ-45 ports, it delivers up to 480Gbps switching capacity, enabling low-latency and high-density connectivity for applications like AI, virtualization, high-speed storage, AVoIP, and video editing.
With Multi-Gig NBASE-T™ technology, it supports 10G / 5G / 2.5G / 1G speeds over existing cabling, while LACP and MC-LAG provide link aggregation and redundancy for high availability. Its Layer 3 Lite routing supports IPv4/IPv6, VLAN, DHCP server, and static routing, giving enterprises the control they need over segmented networks.
The QSW-M3224-24T also offers secure network management with ACL, SNMP, and Qfinder Pro, plus a user-friendly QSS Pro interface for intuitive configuration and monitoring. Built in Taiwan for exceptional reliability, it is ideal for medium to large-scale enterprise environments.
| Feature | Details |
|---|---|
| Brand | QNAP |
| Model | QSW-M3224-24T-US |
| Product Type | Layer 3 Lite Managed Switch |
| Total Ports | 24 x 1/2.5/5/10GBASE-T RJ-45 |
| Management Port | 1 x 1GbE RJ-45 |
| Switching Capacity | 480Gbps |
| Ethernet Standards | IEEE 802.3, 802.3u, 802.3ab, 802.3bz, 802.3an, 802.3x, 802.1Q, 802.1w, 802.3ad, 802.1ab, 802.1p |
| Layer Support | Layer 3 |
| Media Type | Twisted Pair |
| Networking Speeds | 1G, 2.5G, 5G, 10G |
| High Availability | MC-LAG, LACP |
| Security Features | ACL, SNMP, Qfinder Pro login |
| Management Interface | QSS Pro |
| Power Consumption | 116.90W |
| Power Input | AC 12V / 230V, 50–60Hz |
| Form Factor | Rackmount (1U) |
| Dimensions (H x W x D) | 1.7" x 17.3" x 7.5" |
| Weight | 6.46 lbs |
| Certifications | CE, FCC, VCCI, BSMI |
| Warranty | 2-Year Limited Warranty |
| Package Contents | Switch, Power Cord, Rackmount Kit, Quick Installation Guide |
