Description
The Raritan PX3-4281V is a high-accuracy metered inline PDU engineered for demanding data-center power monitoring. It provides per-line, per-breaker, and per-outlet energy metering with ISO/IEC 62053-21 Class 1 accuracy, ensuring precise visibility into load conditions. Designed for operational reliability, it features dual Ethernet ports for redundant networking, optional Wi-Fi, and support for environmental sensors including temperature, humidity, airflow, differential pressure, water leak, and contact closure.
This 208V single-phase PDU delivers up to 5.0 kVA, equipped with 24 × NEMA 5-20R outlets protected by four 20A circuit breakers. A color LCD display provides local monitoring, while remote access is available via HTTP(s), SSH, SNMP, Modbus TCP, and JSON-RPC. With replaceable controllers, cascading support, and robust build quality, the PX3-4281V is ideal for high-density enterprise rack deployments requiring advanced energy intelligence and dependable performance.
| Category | Details |
|---|---|
| Model | Raritan PX3-4281V |
| Input Plug | NEMA L14-30P (3P4W), IP44 |
| Input Voltage | 208V nominal (190–208V rated) |
| Input Current | 30A max |
| Input Frequency | 50/60 Hz |
| Power Capacity | 4.6 kVA @ 190V; 5.0 kVA @ 208V |
| Cord Length | 3 m (9.84 ft), bottom-feed |
| Cable Type | SOOW 4C#10 |
| Output Voltage | 120V nominal (110–120V rated) |
| Outlets | (24) NEMA 5-20R, 16A |
| Overload Protection | (4) LEGBXA6-20 breakers, 5 kAIC |
| Metering Capabilities | Voltage, Current, Active Power, Apparent Power, Power Factor, Energy (kWh); per-line, per-breaker, per-outlet |
| Remote Management | HTTP(s), SSH, Telnet, RS-232, SNMP v2/v3, JSON-RPC, Modbus TCP, Power IQ |
| Networking | Dual Gigabit Ethernet (primary + redundant); optional Wi-Fi (802.11a/b/g/n) |
| Cascading | Up to 32 PDUs via USB + 32 via Ethernet |
| Onboard Display | Color LCD: voltage, current, power, alarms, configuration |
| Environmental Sensor Support | Temp, humidity, airflow, differential pressure, water leak, contact closure |
| Processor | ARM Cortex-A5, 536 MHz; 16MB SPI Flash; 64MB DDR2 RAM |
| Operating Temp | Up to 60°C |
| Humidity | Up to 85% RH |
| Regulatory | UL Listed, ICES-003, FCC Part 15 Class A, RoHS |
| Dimensions (W × D × H) | 2.1" × 2.6" × 60.6" (52 × 65 × 1539 mm) |
| Unit Weight | 5.7 kg |
| Shipping Weight | 7.8 kg |
| Mounting | G2-RACK-FOR-ZU |
| Warranty | 2-year standard |
