Description
The Raritan PX3-5204R-F9 is a high-performance 1U intelligent rack PDU designed for demanding data center and IT environments. It provides advanced energy metering at the inlet, breaker, and individual outlet level, ensuring precise visibility and control of power usage. With remote outlet switching, environmental sensor support, and redundant networking options, it delivers enterprise-grade reliability and management capability.
This model includes 8 IEC C13 outlets, a 32A IEC 60309 plug, and robust overload protection. The onboard color LCD display offers quick local diagnostics, while remote management is supported through HTTP(s), SSH, SNMP, JSON-RPC, and more. Ideal for capacity planning, uptime assurance, and efficient power distribution in modern rack deployments.
| Category | Details |
|---|---|
| Model | PX3-5204R-F9 |
| Form Factor | 1U horizontal |
| Input Plug | IEC 60309 2P+E 32A (IP44) |
| Input Voltage | 200–240V AC (230V nominal) |
| Input Frequency | 50/60 Hz |
| Max Input Current | 32A |
| Power Capacity | 6.4 kVA @ 200V, 7.7 kVA @ 240V |
| Cord Length | 3 m (rear feed) |
| Outlets | (8) IEC C13, 10A |
| SecureLock Support | Yes |
| Overload Protection | (2) LEJBX66-20 breakers |
| Metering | Voltage, Current, Active Power, Apparent Power, Energy, Power Factor |
| Metering Accuracy | IEC 62053-21 ±1% |
| Outlet Switching | Yes (remote) |
| Environmental Sensor Support | Yes (temp, humidity, airflow, differential pressure, water leak, contact closure) |
| Networking | 1× Gigabit Ethernet; 1× redundant 10/100 Ethernet; optional Wi-Fi |
| Remote Management | HTTP(S), SSH, Telnet, RS-232, SNMP v2/v3, SMTP, JSON-RPC, Modbus TCP |
| Cascading | Up to 32 PDUs via USB or Ethernet |
| Onboard Display | Color LCD (voltage, current, power, alarms, configuration) |
| Processor | ARM Cortex-A5, 536 MHz |
| Dimensions (W × D × H) | 17.3" × 7.2" × 1.7" (440 × 183 × 44 mm) |
| Unit Weight | 6.25 kg |
| Operating Temperature | Up to 60°C |
| Regulatory | CE, FCC Part 15 Class A, ICES-003, RoHS |
| Warranty | 2-year manufacturer warranty |
