Description
The Vertiv VP7UU0A0 is a high-performance switched rack PDU (rPDU) offering advanced outlet-level control and monitoring. Designed for critical IT environments, this vertical 0U unit provides 30 locking IEC C13 and 6 locking IEC C19 outlets with a universal inlet. Featuring outlet-level switching, input and outlet monitoring, and support for environmental sensors, it ensures robust power distribution and management. Ideal for modern data centers requiring fault-tolerant daisy chaining and secure network access.
| Feature | Details |
|---|---|
| Part Number | VP7UU0A0 |
| Type | Switched rPDU with Outlet-Level Monitoring |
| Power Capacity | Up to 11.0kW |
| Input Power Options | 48A 1-Phase / 24A 3-Phase Delta / 16A 3-Phase WYE |
| Input Frequency | 50/60Hz |
| Inlet Type | Universal Inlet |
| Outlet Configuration | 30 × IEC C13 (Locking), 6 × IEC C19 (Locking) |
| Monitoring | Input, Outlet, Circuit, Environmental (optional sensors) |
| Switching | Individual outlet on/off switching with sequencing & delays |
| Network Connectivity | Dual 10/100/1000 Mbps Ethernet, Daisy Chain up to 50 rPDUs |
| Protocols Supported | SNMP, HTTP/HTTPS, RADIUS, LDAP, IPv6, Modbus TCP, and more |
| Display | LCD Touchscreen, Auto Orientation |
| Indicators | 36 LEDs |
| Mounting | Vertical (Zero U), Toolless Mounting Kit Included |
| Dimensions (HxWxD) | 72 in x 2 in x 2.6 in (1829 mm x 51 mm x 66 mm) |
| Weight | 27 lbs (12.25 kg) |
| Finish | Black Powder Coat |
| Certifications | UL, CE, UKCA, RoHS, FCC Part 15 Class A, TAA/BAA Compliant |
| Warranty | 5-year limited (with registration), 3-year standard |
| Country of Origin | USA |
