Description
The Vertiv VP5N60AB is a high-performance Switched Rack Power Distribution Unit (rPDU) designed for modern data centers requiring advanced monitoring and remote outlet-level control. This 60A, 208V Delta vertical unit features 48 combination C13/C19 outlets, integrated input and circuit-level power monitoring, and fault-tolerant daisy chaining for scalable network deployment. With optional environmental sensors, robust remote management protocols, and a local high-visibility display, the VP5N60AB delivers reliable power distribution, enhanced visibility, and greater uptime protection.
| Feature | Details |
|---|---|
| Model Number | VP5N60AB |
| Mounting Configuration | Vertical, Zero U |
| Input Power | 60A, 208V Delta, 3 Phase |
| Load Capacity | 17.2kW |
| Outlets | 48x Combination C13/C19 |
| Outlet Grouping | Banks of 6, Color-coded per circuit (6 colors) |
| Outlet Control | Individual outlet switching with time delays |
| Monitoring | Input power, circuit breaker, and environmental (optional sensors) |
| Plug Type | IEC60309 3P+E, IP44 Splashproof |
| Power Cord Length | 10 ft (3 m) |
| Breakers | (6) 20A Double Pole Magnetic, 5kAIC Rated |
| Display | LCD touchscreen with auto orientation |
| Networking | Dual 10/100/1000 Mbps Ethernet, Daisy Chain up to 50 rPDUs |
| Supported Protocols | SNMP, DHCP, HTTP/HTTPS, SSH, Syslog, Modbus TCP, and more |
| Data Formats | CSV, JSON API, JSON Datalog |
| USB and Serial Ports | Yes; RS232 via RJ45 |
| Environmental Monitoring Ports | 1 RJ-type port (supports up to 16 sensors) |
| Chassis Dimensions (LxWxD) | 78in x 3.8in x 2.6in (1982mm x 97mm x 66mm) |
| Weight | 26 lbs (11.79 kg) |
| Operating Temperature | Max 60°C (140°F) |
| Chassis Finish | Heavy steel with black powder coat |
| Certifications | UL & c-UL 62368-1, RoHS, FCC Part 15 Class A |
| Warranty | 5-year limited (with registration), otherwise 3 years |
| Country of Origin | USA, TAA and BAA COTS Compliant |
