Description
The Vertiv VP5UV0A1 is a high-performance switched rack PDU (rPDU) designed for enterprise-grade IT environments requiring robust remote power management and monitoring. Featuring 24 combination C13/C19 outlets, a universal inlet, and support for up to 22.0kW power capacity, this vertical rPDU offers precise unit-level monitoring, outlet-level switching, and environmental sensor support. Its fault-tolerant daisy chaining, residual current metering (Type B), and dual-network connectivity ensure maximum uptime and scalability in dynamic data center deployments.
| Specification | Details |
|---|---|
| Model | VP5UV0A1 |
| Type | Switched rPDU with Unit Level Monitoring |
| Input Power Capacity | Up to 22.0kW (32A 3-Phase WYE, 240/415V Max) |
| Plug Type | Universal Inlet |
| Receptacles | 24 × Combination C13/C19 |
| Orientation | Vertical (Zero U) |
| Monitoring | Input Power, Circuit/Breaker, Residual Current (Type B) |
| Switching | Individual Outlet Switching with Delay Options |
| Communication Ports | Dual 10/100/1000 Ethernet, USB, RS232 (RJ45) |
| Network Protocols | SNMP (v1/v2c/v3), HTTPS, SSH, RADIUS, TACACS+, Modbus TCP, Syslog, etc. |
| Environmental Monitoring | Supports optional sensors (up to 16 via RJ connection) |
| Display | LCD Touchscreen with Auto Orientation |
| Breakers | 6 × 16A Double Pole Magnetic Breakers (10kAIC Rated) |
| Mounting | Toolless (61.25in / 64.75in spacing); includes UPDU mounting bracket |
| Finish | Black Powder-Coated Heavy Steel |
| Dimensions (L×W×D) | 66.25in × 2in × 2.6in (1683mm × 51mm × 66mm) |
| Weight | 27 lbs (12.25 kg) |
| Operating Temperature | Up to 60°C (140°F) |
| Compliance | CE, UKCA, RoHS, TAA, BAA, IEC 62368-1, EN 55032/55035 |
| Warranty | 5-Year Limited (if registered within 120 days) |
| Country of Origin | USA |
