Description
The ASUS RS500A-E11-WOCPU006Z is a high-performance 1U rackmount server powered by the latest AMD EPYC™ 7003 series processors, engineered for data centers and enterprise workloads demanding maximum scalability, security, and efficiency. With support for up to 16 DIMMs, 12 NVMe/SATA drive bays, and three PCIe® 4.0 expansion slots, it delivers exceptional bandwidth and storage throughput. Integrated ASMB10-iKVM with ASPEED AST2600 ensures robust out-of-band management, while OCP 3.0 NIC support provides future-ready networking up to 200 Gbps. Designed with PFR FPGA firmware protection, tool-less servicing, and efficient air cooling, the RS500A-E11 offers optimized power usage and reliability for AI, HPC, and virtualized environments.
| Category | Specification |
|---|---|
| Model | ASUS RS500A-E11-WOCPU006Z |
| Form Factor | Rack-mountable 1U |
| Processor Support | AMD EPYC™ 7003 Series (Socket SP3, up to 64 cores, 280W TDP) |
| CPU Configuration | 1-way, No CPU included |
| Chipset | System on Chip (SoC) architecture |
| Memory Support | 16 x DIMM slots, up to 2048 GB DDR4 3200 MHz, RDIMM/LRDIMM/3DS LRDIMM |
| Storage Bays | 12 x 2.5" hot-swap NVMe/SATA (front) + optional 4 x 2.5" NVMe/SATA (middle) |
| Storage Interface | PCIe 4.0 NVMe, SATA, SAS (via optional controller) |
| Expansion Slots | 3 x PCIe 4.0 (2 x16 + 1 x16/x8), 1 x OCP 3.0 NIC slot |
| M.2 Slots | 2 x PCIe 4.0 x4 (2280/22110) |
| Network Interface | 2 x Intel I350-AM2 Gigabit Ethernet, 1 x management port |
| Graphics | ASPEED AST2600 (dedicated BMC graphics) |
| Management | ASUS ASMB10-iKVM (IPMI, Redfish®, WebGUI) |
| Security | Platform Firmware Resilience (PFR) FPGA, TPM 2.0 (optional) |
| Cooling Solution | Air-cooled with standard heatsink |
| Power Supply | Dual 800W 80 PLUS Platinum redundant PSUs |
| Operating System | No OS preinstalled |
| Compliant Standards | FCC Class A, BSMI, RoHS |
| Dimensions (W x D x H) | 44.9 x 84.25 x 4.4 cm |
| Weight | 17 kg (22 kg shipping) |
| Operating Temperature | 10°C – 35°C |
| Included Accessories | ASMB10-iKVM remote management card |
| Product Color | Black |
