Description
The ASUS RS500A-E12-RS12U-12W12B is a compact, high-performance 1U rack server built to handle demanding enterprise and general-purpose workloads. Powered by 4th Gen AMD EPYC™ 9004 series processors with AMD 3D V-Cache™ technology, it delivers exceptional computational power, scalability, and energy efficiency in a space-saving chassis.
Designed for flexibility, the RS500A-E12-RS12U-12W12B supports 24 DDR5 4800 MHz DIMM slots for up to 6 TB of memory, twelve 2.5-inch hot-swap bays with an optional internal 4-bay cage for up to 16 drives, and PCIe Gen 5 expansion for advanced acceleration and connectivity. Its dual Intel I350-AM2 Gigabit LAN and OCP 3.0 slot enable flexible network configurations, while the redundant 80 PLUS Platinum/Titanium CRPS power supplies ensure high reliability.
With ASUS ASMB11-iKVM and ASUS Control Center, IT administrators benefit from complete in-band and out-of-band management, making deployment and monitoring seamless across data centers. The RS500A-E12-RS12U-12W12B sets a new standard in performance, manageability, and density for modern enterprise infrastructure.
| Category | Specification |
|---|---|
| Processor | 1 × Socket SP5 (LGA-6096), supports 4th Gen AMD EPYC™ 9004 series processors (up to 400 W TDP) |
| Memory | 24 × DDR5 4800 MHz DIMM slots, 12-channel architecture, up to 6,144 GB RDIMM / 3DS RDIMM |
| Expansion Slots | 3 × PCIe Gen 5 x16 (FH HL / LP HL configurable), 1 × OCP 3.0 (Gen 5 x16 link) |
| Storage Bays | 12 × 2.5" hot-swap SATA/SAS/NVMe (U.2 or U.3) front bays; optional 4-bay internal cage (mid bay SKU) |
| M.2 Support | 2 × M.2 sockets (PCIe Gen 4 x4 or SATA, up to 22110 module) |
| Networking | 2 × 1 GbE RJ45 (Intel I350-AM2), 1 × dedicated management port (AST2600 BMC) |
| GPU Support | Up to 2 × single-slot GPU cards (depending on NVMe configuration) |
| Security | Optional TPM module; optional PFR module |
| Management | ASUS Control Center (in-band), ASMB11-iKVM (BMC AST2600 out-of-band) |
| I/O Ports (Rear) | 2 × USB 3.2 Gen 1, 2 × LAN (RJ45), 1 × Management RJ45, 1 × VGA, 1 × COM |
| Power Supply | 1 + 1 Redundant 1200 W / 1600 W 80 PLUS Platinum or Titanium CRPS (Region dependent) |
| Dimensions (W × D × H) | 449 × 842.5 × 43.85 mm (17.68" × 33.15" × 1.73") |
| Weight | Net 14.16 kg / Gross 19.16 kg (excluding CPU, DRAM, HDD) |
| Operating Temperature | 10 °C – 35 °C |
| Compliance & Certifications | CE, FCC, CB, BSMI, UL (availability may vary by region) |
