Description
The ASUS RS700-E11-RS12U-16W10G is a high-performance 1U rackmount server built to deliver scalable compute power for demanding enterprise workloads, AI acceleration, and high-performance computing (HPC). Powered by dual 4th/5th Gen Intel® Xeon® Scalable processors, it supports up to 32 DDR5 DIMMs, PCIe 5.0, and 12 NVMe/SATA/SAS drive bays for exceptional data throughput and efficiency.
With flexible configuration options—such as one dual-slot GPU, OCP 3.0 support, and ASUS ASMB11-iKVM remote management—the RS700-E11-RS12U-16W10G is optimized for AI, data analytics, virtualization, and cloud computing environments. Its robust redundant 1200W/1600W 80 PLUS Platinum/Titanium PSU, advanced thermal design, and enterprise-grade security (TPM 2.0, PFR FPGA) ensure reliability and operational integrity for mission-critical applications.
| Category | Specification |
|---|---|
| Processor Support | Dual Socket E (LGA 4677), 4th/5th Gen Intel® Xeon® Scalable Processors, up to 350W TDP |
| Chipset | Intel® C741 PCH |
| Memory | 32 DIMM slots (8-channel per CPU), DDR5 5600/5200/4800/4400 RDIMM/RDIMM 3DS, up to 4–8TB capacity |
| GPU Support | 1 dual-slot GPU (e.g., NVIDIA A100) for AI/HPC workloads |
| Expansion Slots | Up to 3+1 PCIe 5.0 slots (2 x FHFL x16, 1 x LP x16, 1 x Internal PIKE x8), OCP 3.0 optional |
| Storage Bays | 12 x 2.5” hot-swap bays (NVMe/SATA/SAS*), 2 x M.2 (up to 2280, SATA/PCIe Gen4 x8 link) |
| Storage Controller | 12 x SATA 6Gb/s ports; optional Broadcom HBA/RAID cards (9500-8i, 9540-8i, 9560-16i) |
| Networking | 1 x Quad Port Intel® I350-AM4 1G LAN or Dual Port Intel® X710-AT2 10G LAN; 1 x Management Port |
| Graphics | ASPEED AST2600 64MB |
| Front I/O Ports | 2 x USB 3.2 Gen 1, 1 x VGA |
| Rear I/O Ports | 2 x USB 3.2 Gen 1, 1 x VGA, 1 x RJ-45 (Mgmt LAN), 2 x 10G or 4 x 1G RJ-45 GbE |
| Management | ASUS Control Center (Classic); ASMB11-iKVM (KVM-over-IP) |
| Power Supply | 1+1 Redundant AC 1200W/1600W 80 PLUS Platinum/Titanium PSU |
| Cooling System | 8 x Hot-swap fans; supports enhanced air-cooling (EVAC) design |
| Security | PFR FPGA Root-of-Trust, TPM 2.0 |
| Dimensions (W x D x H) | 439.5 mm x 842.5 mm x 44 mm (1U) |
| Weight | Net: 13.7 kg / Gross: 22.56 kg |
| Operating Temperature | 10°C ~ 35°C |
| Supported OS | Windows Server 2019/2022, RHEL, SUSE Linux, CentOS, Ubuntu, VMware |
| Target Applications | HPC, AI workloads, virtualization, data warehousing, cloud environments |
