Description
The ASUS RS700A-E12-RS4U is a high-performance 1U rackmount server designed for data centers and enterprise workloads requiring superior compute density and I/O flexibility. Powered by dual AMD EPYC™ 9004 (Genoa) processors, it supports up to 3072 GB of DDR5 memory across 24 DIMM slots, ensuring maximum performance for virtualization, HPC, and cloud environments.
This server provides four hot-swap 3.5-inch drive bays with SATA/PCIe interfaces, PCIe 5.0 expansion, and dual 10 Gigabit Ethernet (Intel X710-AT2) for ultra-fast networking. It integrates the ASPEED AST2600 management controller and ASMB10-iKVM remote management for comprehensive system monitoring and control. With redundant 1600W 80 PLUS Platinum power supplies, the RS700A-E12-RS4U delivers exceptional reliability and energy efficiency ideal for demanding enterprise deployments.
| Category | Specification |
|---|---|
| Model | ASUS RS700A-E12-RS4U-16W1G |
| Form Factor | Rack-mountable – 1U |
| Processor Support | Dual-socket (2-way) AMD EPYC™ 9004 Series (Socket SP5) |
| CPU Installed | None (supports up to 2 CPUs) |
| Chipset / BMC | ASPEED AST2600 with ASUS ASMB10-iKVM |
| Memory Type | DDR5 SDRAM (12-channel, registered, 3DS supported) |
| Memory Slots | 24 DIMM (up to 3072 GB max) |
| Storage Bays | 4 x 3.5" hot-swap bays (SATA/PCIe interface) |
| Storage Controller | 1 x SATA 6Gb/s, 4 channels |
| Expansion Slots | 1 x PCIe 5.0 x16 (full-height), 1 x PCIe 5.0 x16 (low-profile), 1 x PCIe 4.0 x8 (low-profile), 1 x OCP 3.0 (x16) |
| Networking | 2 x 10 Gigabit Ethernet (Intel X710-AT2) |
| Video Output | ASPEED AST2600 (64 MB video memory), VGA ports (front & rear) |
| USB Ports | 4 x USB 3.2 Gen 1 (2 front, 2 rear) |
| Management Port | 1 x dedicated RJ-45 for management |
| Power Supply | 2 x 1600W redundant PSUs, 80 PLUS Platinum certified |
| Dimensions (W x D x H) | 44.9 x 84.25 x 4.385 cm |
| Weight | 13.93 kg (net), 18.93 kg (shipping) |
| Operating Temperature | 10°C – 35°C |
| Compliances | FCC Class A, BSMI, CB, C-Tick |
| Included Accessories | ASMB10-iKVM Remote Management Card |
| Operating System | None (OS-ready) |
| Color | Black/Silver |
