Description
The ASUS RS720-E11-RS12U is a high-performance 2U rack server designed for compute-intensive workloads, AI acceleration, and virtualization environments. Powered by dual-socket 4th and 5th Gen Intel® Xeon® Scalable processors, it supports up to 32 DDR5 DIMMs and offers exceptional expandability with 9 PCIe 5.0 slots and 12 NVMe/SATA/SAS hot-swap bays.
Engineered for modern data centers, the RS720-E11-RS12U provides flexible cooling options with enhanced air solutions and redundant 2600W/1600W 80 PLUS Titanium/Platinum power supplies. Advanced security is ensured through Platform Firmware Resilience (PFR) FPGA Root-of-Trust and TPM 2.0, while the ASMB11-iKVM enables full remote management and monitoring. With support for up to three dual-slot GPUs, this server is ideal for high-performance computing (HPC), AI forecasting, data warehousing, and virtualization workloads.
| Category | Specification |
|---|---|
| Processor | Dual-socket (LGA 4677) supporting 4th/5th Gen Intel® Xeon® Scalable Processors (up to 350W TDP) |
| Chipset | Intel® C741 PCH |
| Memory | 32 x DIMM slots (8-channel per CPU, DDR5 5600/5200/4800/4400 RDIMM/RDIMM 3DS) |
| Max Memory Capacity | Up to 8 TB (DDR5 + Crow Pass) |
| GPU Support | Up to 3 dual-slot GPUs (e.g., NVIDIA A100) |
| Expansion Slots | 9 total (6 × PCIe 5.0 x8 or 3 × PCIe 5.0 x16, 1 × PCIe 5.0 x16 FHHL, 1 × PCIe 5.0 x16 LP, 1 × OCP 3.0 Gen5 x16 FHHL) |
| Storage Bays | 12 × 3.5” hot-swap bays (supporting NVMe/SATA/SAS), 2 × M.2 (SATA/PCIe, up to 2280) |
| RAID / Storage Controller | 12 x SATA 6Gb/s ports; optional Broadcom RAID/HBA cards (9540-8i, 9560-16i, 9500-8i) |
| Network | 1 × Quad-Port Intel I350-AM4 1G LAN or 1 × Dual-Port Intel X710-AT2 10G LAN (optional) + 1 × Management Port |
| Graphics | ASPEED AST2600 64 MB |
| Front I/O Ports | 2 × USB 3.2 Gen1, 1 × VGA |
| Rear I/O Ports | 2 × USB 3.2 Gen1, 1 × VGA, 1 × RJ-45 Management Port, 2 × 10G or 4 × 1G LAN (optional) |
| Power Supply | 1+1 Redundant 2600W/1600W 80 PLUS Titanium/Platinum PSU |
| Cooling | 4 × Hot-swap fans with air-cooled or EVAC heatsink options |
| Security | PFR FPGA Root-of-Trust, TPM 2.0 |
| Management | ASUS Control Center (Classic), On-board ASMB11-iKVM (KVM-over-IP) |
| Operating Systems | Windows Server 2019/2022, RedHat, SuSE, CentOS, Ubuntu, VMware |
| Dimensions (W × D × H) | 447 × 840 × 88 mm (2U) |
| Net Weight | 18.195 kg (without CPU/DRAM/HDD) |
| Operating Temperature | 10°C – 35°C |
| Target Applications | HPC, AI workloads, data warehousing, and virtualization |
