Description
The ASUS RS720-E11-RS24U-20WGP10G is a high-performance 2U rack server engineered for data centers, AI workloads, and HPC environments. Powered by dual-socket 4th/5th Gen Intel® Xeon® Scalable processors, it supports up to 32 DDR5 DIMMs, PCIe 5.0 architecture, and 24 hot-swappable NVMe bays for exceptional throughput. Designed for GPU acceleration, it accommodates up to four dual-slot GPUs, making it ideal for demanding compute, virtualization, and AI-driven applications. With redundant 2600W 80 PLUS Titanium/Platinum power supplies, ASMB11-iKVM remote management, and flexible 10G/1G LAN options, the RS720-E11-RS24U delivers scalability, reliability, and energy-efficient performance for modern enterprise workloads.
| Category | Specification |
|---|---|
| Processor Support | Dual Socket E (LGA 4677); 4th/5th Gen Intel® Xeon® Scalable Processors (up to 350W TDP per CPU) |
| Chipset | Intel® C741 PCH |
| Memory | 32 DIMM slots (16 per CPU); DDR5 5600/5200/4800/4400 RDIMM / RDIMM 3DS (up to 4–8 TB capacity) |
| GPU Support | Up to 4 dual-slot GPUs (NVIDIA-ready for AI/HPC) |
| Expansion Slots | 4 x PCIe 5.0 slots (2 x Gen5 x8 or 1 x Gen5 x16, 1 x OCP 3.0, 1 x Gen5 x16 LP) |
| Storage Bays | 24 x 2.5" hot-swap bays (SATA/SAS/NVMe), 2 x M.2 (SATA/PCIe Gen4 x8) |
| RAID / SAS Options | Optional Broadcom HBA 9500-8i, MegaRAID 9540-8i / 9560-16i (12G SAS) |
| Networking | 1 x Dual Port Intel® X710-AT2 10G LAN Controller or Quad Port Intel® I350-AM4 1G LAN Controller; 1 x Management Port |
| Graphics | ASPEED AST2600 (64MB) |
| Front I/O Ports | 2 x USB 3.2 Gen1, 1 x VGA |
| Rear I/O Ports | 2 x USB 3.2 Gen1, 1 x VGA, 1 x RJ-45 (Mgmt), 2 x 10G or 4 x 1G RJ-45 LAN |
| Management | ASUS Control Center (Classic); ASMB11-iKVM for KVM-over-IP |
| Power Supply | 1+1 Redundant 2600W/1600W 80 PLUS Titanium/Platinum PSU |
| Cooling | 4 x Hot-swap fans; air-cooled with optional enhanced EVAC heatsink |
| Security | PFR FPGA Root-of-Trust, TPM 2.0 |
| Operating Systems | Windows Server 2019/2022, RedHat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Ubuntu, VMware |
| Dimensions (W x D x H) | 447 x 840 x 88 mm (2U) |
| Weight | Net: 25.64 kg; Gross: 36 kg |
| Operating Temperature | 10°C to 35°C |
| Use Case | HPC, AI, Virtualization, Data Warehousing, Cloud Applications |
