Description
The ASUS RS720A-E12-RS24U-2KW10G is a high-performance 2U dual-socket server built for enterprise storage, cloud, and virtualized workloads. Powered by 4th Gen AMD EPYC™ 9004 Series processors with AMD 3D V-Cache™ technology, it supports up to 24 DIMMs of DDR5 memory and PCIe 5.0 expansion for optimal data throughput.
Designed with a front-parallel CPU and memory layout, this server ensures superior thermal efficiency and reliable rack performance. It offers up to 24 x 2.5” hot-swap bays supporting mixed NVMe/SATA/SAS configurations, dual M.2 slots, and redundant 2000 W 80 PLUS Platinum power supplies for high availability.
With enhanced security features like PFR FPGA Root-of-Trust and TPM 2.0, plus integrated ASMB11-iKVM and ASUS Control Center (ACC) for remote management, the RS720A-E12-RS24U delivers robust performance and resiliency for mission-critical applications across modern data centers.
| Category | Details |
|---|---|
| Model | ASUS RS720A-E12-RS24U-2KW10G |
| Form Factor | 2U Rackmount Server |
| Processor Support | 2 × Socket SP5 (LGA 6096), AMD EPYC™ 9004 Series (up to 400 W TDP), with AMD 3D V-Cache™ Technology |
| Core Logic | Integrated I/O (No Chipset) |
| Memory | 24 × DIMM slots (12 per CPU), DDR5-4800/4400 RDIMM/LRDIMM/3DS, Max Capacity 6144 GB |
| Storage Bays | 24 × 2.5" Hot-Swap Drive Bays (Support 16 × NVMe + 8 × NVMe/SATA/SAS), 2 × M.2 (Up to 2280) |
| Storage Controller | 8 × SATA 6 Gb/s ports; Optional Broadcom HBA 9500-16i / MegaRAID 9540-8i / 9560-16i |
| Expansion Slots | 9 × PCIe Gen5 Slots + 1 × Internal RAID Slot • 3 × PCIe Gen5 x16 (FHFL) • 1 × PCIe Gen5 x16 or OCP 3.0 (FHFL) • 1 × PCIe Gen5 x16 (LP) |
| GPU Support | Up to 3 dual-slot GPUs (e.g., NVIDIA A100) for AI and compute acceleration |
| Network | 1 × Dual-Port Intel X710-AT2 10 GbE LAN Controller (or Quad-Port 1 GbE Option), + 1 × Mgmt LAN |
| Graphics | ASPEED AST2600 64 MB |
| Management | ASUS Control Center (Classic), On-board ASMB11-iKVM (KVM over IP) |
| Security | PFR FPGA Root-of-Trust, TPM 2.0 |
| I/O Ports (Front) | 2 × USB 3.2 Gen 1 |
| I/O Ports (Rear) | 2 × USB 3.1 Gen 1, 1 × VGA, 1 × Mgmt LAN, 2 × 10 G RJ-45 Ports (or 4 × 1 G Option), 1 × OCP 3.0 (Optional) |
| Operating Systems | Windows Server 2019, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Ubuntu, VMware |
| Power Supply | 1 + 1 Redundant 2000 W 80 PLUS Platinum Hot-Swap PSU (also supports 1600 W variant) |
| Cooling | 4 × Hot-Swap Fans with Enhanced Volume Air Cooling (EVAC) Heatsink + Dedicated GPU Fan |
| Dimensions (W × D × H) | 449 mm × 840 mm × 88.1 mm (17.68 × 33.07 × 3.47 in) |
| Weight | Net: 20.3 kg • Gross: 26.77 kg |
| Operating Environment | Operating: 10 °C – 35 °C • Non-Operating: -40 °C – 60 °C • Humidity: 20 % – 90 % (non-condensing) |
| Regulatory Compliance | BSMI, CE, CB, FCC (Class A), ENERGY STAR Computer Servers v4.0 |
