Description
The ASUS RS720Q-E7/RS12 is a high-density 2U rackmount server designed for HPC and clustered computing environments. Engineered with four independent computing nodes, each supporting dual Intel Xeon processors (LGA2011) and up to 512 GB of DDR3 ECC memory, it delivers exceptional scalability and reliability. Built on the Intel C602-A chipset, the RS720Q-E7/RS12 ensures optimized performance, efficient power management, and easy system maintenance through ASUS ASWM 2.0 for remote administration.
Featuring hot-swappable 3.5" drive bays, redundant 1620W 80 PLUS Platinum power supplies, and multiple Gigabit Ethernet connections, this system is built for continuous operation and energy efficiency. The integrated ASPEED AST2300 graphics controller provides basic display support, while its tool-less design and rack rail kit simplify installation and serviceability—ideal for data centers and enterprise deployments requiring flexibility, performance, and density.
| Category | Specification |
|---|---|
| Model | ASUS RS720Q-E7/RS12 |
| Form Factor | Rack-mountable 2U Cluster (4 Nodes) |
| Server Scalability | 2-way per node |
| Chipset | Intel C602-A |
| Processor Socket | LGA2011 (supports up to 2 CPUs per node) |
| CPU Installed | None (CPU required) |
| CPU Upgradability | Upgradable |
| Max CPU Quantity | 2 per node |
| Memory Type | DDR3 ECC SDRAM (Unbuffered / Registered / LRDIMM) |
| Memory Slots | 16 x DIMM 240-pin |
| Max Memory Capacity | 512 GB registered / 128 GB unbuffered |
| Memory Installed | 0 GB |
| Storage Bays | 3 x hot-swap 3.5" (per node) |
| Hard Drives Installed | None |
| Storage Controller | SATA 3Gb/s & SATA 6Gb/s, RAID 0/1/5 |
| Graphics Controller | ASPEED AST2300 (16 MB shared memory) |
| Video Interface | VGA |
| Network Controller | 2 x Intel 82574L Gigabit Ethernet |
| LAN Ports | 2 x RJ-45 (per node) + 1 x management port |
| Expansion Slots | 1 x PCIe 3.0 x16 (half-length, low-profile) |
| Interfaces | 2 x USB 2.0, 1 x serial, 1 x VGA, 1 x internal USB |
| Power Supply | 2 x 1620W hot-plug redundant PSU, 80 PLUS Platinum |
| Cooling | Redundant system fans |
| Management Software | ASUS ASWM 2.0 (Web-based Management) |
| Compliance | FCC Class A, C-Tick, BSMI, EN55022, EN55024 |
| Included Accessories | Rack rail kit |
| Operating Temperature | 10°C – 35°C |
| Dimensions (W x D x H) | 44.4 x 75 x 8.7 cm |
| Weight | 25 kg |
| UNSPSC | 43211501 |
| Category | Servers |
| Manufacturer | ASUS |
| Product Type | Hardware |
