Description
The Synology RackStation RS822+ is a compact yet powerful 4-bay rackmount NAS engineered for high-performance storage and data protection in small to medium-sized businesses and branch offices. Powered by the AMD Ryzen™ V1500B quad-core processor and the Synology DiskStation Manager (DSM) operating system, it delivers over 2,100 MB/s sequential read and 1,000 MB/s sequential write throughput, ensuring fast file access, sharing, and backup across teams.
Designed for scalability and flexibility, the RS822+ supports up to 8 drives when paired with the RX418 expansion unit and up to 32 GB DDR4 ECC memory for enhanced reliability. Four 1 GbE LAN ports enable link aggregation and network failover, with optional 10 GbE or 25 GbE network cards for faster connectivity.
Built on the Btrfs file system, the RS822+ safeguards data with snapshot replication, file self-healing, and inline compression, ensuring long-term data integrity. Synology’s comprehensive Active Backup Suite, Hyper Backup, and C2 Cloud integration provide a complete data protection solution for hybrid environments.
Ideal for file sharing, synchronization, surveillance, and virtualization, the RS822+ integrates seamlessly with Windows, macOS, Linux, and popular hypervisors, making it a reliable foundation for enterprise-grade storage and collaboration.
| Category | Specification |
|---|---|
| CPU | AMD Ryzen V1500B quad-core 2.2 GHz (64-bit) |
| Hardware Encryption | Yes |
| System Memory | 2 GB DDR4 ECC SODIMM (1×2 GB, expandable to 32 GB [2×16 GB]) |
| Drive Bays | 4 × 3.5" SATA HDD / 2.5" SATA SSD (hot-swappable) |
| Maximum Drive Bays | 8 with Synology RX418 expansion unit |
| Form Factor | 1U Rackmount |
| LAN Ports | 4 × 1 GbE RJ-45 (aggregable / failover support) |
| PCIe Slot | 1 × Gen3 (x4 link) for 10/25 GbE NIC or M.2 SSD adapter |
| USB Ports | 2 × USB 3.2 Gen 1 |
| Expansion Port | 1 × eSATA |
| File System (Internal) | Btrfs, ext4 |
| File Protocols | SMB, AFP, NFS, FTP, WebDAV, Rsync |
| RAID Support | SHR, Basic, JBOD, RAID 0/1/5/6/10 |
| Max Volume Size | 108 TB per volume (64 volumes max) |
| Operating System | Synology DiskStation Manager (DSM) |
| Virtualization Support | VMware vSphere, Microsoft Hyper-V, Citrix XenServer, OpenStack Cinder |
| Surveillance Support | Up to 40 IP cameras (H.265/H.264), 2 free licenses included |
| Dimensions (H × W × D) | 44 mm × 480 mm × 492.6 mm |
| Weight | 6.4 kg |
| Operating Temperature | 0 °C to 35 °C (32 °F to 95 °F) |
| Power Input | 100 V – 240 V AC, 50/60 Hz Single Phase |
| Warranty | 3-year hardware warranty (extendable to 5 years with EW202 or Extended Warranty Plus) |
