Description
The Server Technology® PRO2 C2WG24SN-2CJN5D6 Switched POPS PDU delivers advanced power distribution and monitoring for high-density data centers. Featuring 18 x C13 and 6 x Cx hybrid outlets, this PDU combines PIPS® (Per Inlet Power Sensing) and POPS® (Per Outlet Power Sensing) technologies for billing-grade measurement accuracy of current, voltage, power, crest factor, and energy usage.
With remote outlet control, IT staff can safely reboot locked equipment, manage unused receptacles, and balance loads across phases. Star Multi-Linking allows up to four circuits under a single IP address, while the hot-swap network card ensures uninterrupted access.
The unit supports environmental monitoring via temperature/humidity probes, offers branch circuit protection with UL-compliant breakers, and provides rich network connectivity (HTTP/S, SNMP, SSH, Telnet, LDAP, RADIUS, TACACS+, and more). Its high-retention locking outlets and optional accessories improve safety and cable management, making it ideal for mission-critical environments.
| Category | Details |
|---|---|
| Manufacturer | Server Technology, Inc. (Legrand Group) |
| Series / Model | PRO2 / C2WG24SN-2CJN5D6 |
| PDU Type | Switched POPS (Per Outlet Power Sensing) |
| Outlets | (18) x IEC C13, (6) x Cx (hybrid C13/C19) |
| Input Voltage | 208V, 50/60 Hz |
| Input Plug | NEMA L6-30P |
| Input Current | 30A (24A rated) |
| Power Capacity | 5.0 kW |
| Branch Circuit Protection | UL 489, CSA C22.2 No. 5, IEC/EN 60947-2; (3) x 2-pole, 20A trip breakers |
| Network Connectivity | 10/100/1000 Mbps Ethernet (RJ-45), RS-232, SNMPv2c/v3, SSH, Telnet, LDAP(S), TACACS+, RADIUS, HTTP/HTTPS |
| Environmental Monitoring | 2 x external temperature/humidity probes supported |
| Physical Dimensions | 3.5" H x 17.2" W x 17.5" D (89 x 437 x 445 mm) |
| Operating Environment | 32°F to 122°F (0°C to 50°C), 8–90% RH (non-condensing) |
| Storage Environment | -22°F to 176°F (-30°C to 80°C), up to 50,000 ft (15 km) elevation |
| Certifications | UL 62368-1, CSA C22.2 No. 62368-1, FCC Class A, CAN ICES-003 Class A |
| Warranty | 2-year limited parts & labor (extended options available) |
