Description
The Server Technology® PRO1 Smart PDU (Primary) provides intelligent power distribution with real-time monitoring and advanced management features for high-density data centers. Equipped with PIPS® (Per Inlet Power Sensing) technology, this unit delivers billing-grade measurement of current, voltage, power, and energy. IT administrators gain visibility and control through Web, CLI, or SNMP interfaces, ensuring optimal load balancing and proactive alerts.
The C1S15HN-DFJN5BC3-013 model supports local LED input current monitoring, hot-swap network cards, and environmental monitoring (via optional probes). With branch circuit protection, high-retention locking outlets, and multi-linking capability, it offers a secure and scalable solution for enterprise-grade power distribution.
| Category | Details |
|---|---|
| Manufacturer | Server Technology, Inc (Legrand Group) |
| Product Line | PRO1 |
| Model | C1S15HN-DFJN5BC3-013 (Primary) |
| Product Type | Smart Switched PDU |
| Outlets | 15 total (3 × IEC 60320 C13, 12 × IEC 60320 C19) |
| Input Voltage | 208V |
| Input Plug | CS8365 3P+G, 50A |
| Input Current | Rated 40A (50A max), 14.4kW capacity |
| Phase | Three-phase |
| Monitoring | Local LED input current display; PIPS® technology |
| Networking | Ethernet 10/100/1000 Mbps, RS-232; supports HTTP(S), SSH, Telnet, SNMP, FTP/SFTP, LDAP(S), RADIUS, TACACS+, IPv4/IPv6 |
| Environmental Support | Two external 10’ temperature/humidity probe inputs (optional) |
| Branch Circuit Protection | UL 489 magnetic-hydraulic circuit breakers (six × 2-pole, 20A) |
| Physical Dimensions | 3.5" H × 17.2" W × 10.1" D (89 × 437 × 257 mm) |
| Operating Conditions | 32°F–122°F (0°C–50°C), 8–90% RH, up to 6,500 ft (2 km) |
| Certifications | UL 62368-1, CSA C22.2 No. 62368-1, FCC Class A, CAN ICES-003 Class A |
| Power Accuracy | ±1% for current, voltage, power, and energy |
| Warranty | 2-year limited (extended options available) |
| Optional Accessories | EMTH-2-10 probes, EMCU-1-1C monitor, EMWS-1-1 sensor, cable retention devices, mounting kits |
