Description
The Server Technology PRO1 Smart PDU C1S42CA-DQME2700 is engineered for reliable power distribution and intelligent monitoring in demanding data center environments. Featuring 42 x IEC C13 outlets, this Primary PDU supports 17.3 kW of power capacity at 208V, making it ideal for high-density racks.
Equipped with PIPS® (Per Inlet Power Sensing) technology, it delivers accurate measurement of current, voltage, active and apparent power, energy, and power factor. The unit also supports temperature and humidity monitoring with optional probes, providing SNMP-based alerts for proactive management.
Designed for resilience, the hot-swappable network card ensures continuous monitoring even during maintenance. Additional benefits include alternating-phase outlets for balanced loads, HDOT® (High Density Outlet Technology), branch circuit protection, and compliance with UL 62368-1 and IEC 62368-1 standards.
Perfect for enterprises needing real-time visibility, secure network connectivity, and high-density, efficient power distribution, the C1S42CA-DQME2700 helps data centers maximize uptime and optimize power usage.
| Category | Details |
|---|---|
| Manufacturer | Server Technology (Legrand) |
| Product Line | PRO1 Smart PDU |
| Model | C1S42CA-DQME2700 (Primary) |
| Outlet Quantity | 42 x IEC 60320 C13 |
| Input Voltage | 208V, 50/60 Hz |
| Input Plug | IEC 60309 3P+G 9Hr, 60A |
| Input Current Rated | 48A |
| Power Capacity | 17.3 kW |
| Branch Circuit Protection | 6x UL 489 2-pole breakers, ≤16A each |
| Monitoring | PIPS® (Per Inlet Power Sensing), Auto-Flip Current Display |
| Network Connectivity | HTTP(S), SSH, Telnet, SNMP v2/v3, LDAP(S), RADIUS, Syslog |
| Sensors | 2x external T/H probe inputs (optional) |
| Temperature Range | 0°C to 60°C (operating) |
| Mounting Options | Button mounts, custom brackets, flexible mounting |
| Certifications | UL 62368-1, CSA C22.2, FCC Part 15 Class A, CAN ICES-003 |
| Dimensions (HxWxD) | 70.0” x 1.75” x 3.0” (1778mm x 45mm x 77mm) |
| Weight | [Not listed – insert if available] |
| Warranty | 2-year limited (extended options available) |
