Description
The Server Technology PRO1 Smart PDU STV-3534D (Primary) delivers intelligent power distribution and advanced monitoring for modern data centers. Featuring PIPS® (Per Inlet Power Sensing) technology, it provides billing-grade accurate measurements of current, voltage, active and apparent power, power factor, crest factor, and energy usage. The unit includes local LED input current monitoring for per-phase load management, reducing the risk of overloads during installation.
With hot-swappable network cards, multi-linking capability, and support for environmental monitoring via optional probes, the STV-3534D offers secure and reliable remote access through HTTP(S), SSH, Telnet, SNMP, and more. Built to perform in high-density data center environments, it operates safely up to 60°C and includes high-retention locking outlets for secure connectivity.
Designed for flexible mounting with Power Pivot™ rotatable cord routing and available in multiple color-coded options, the STV-3534D ensures dependable power distribution, operational efficiency, and future-ready scalability for mission-critical IT infrastructure.
| Category | Details |
|---|---|
| Manufacturer | Server Technology (Legrand) |
| Product Series | PRO1 Smart PDU |
| Model / SKU | STV-3534D (Primary) |
| PDU Type | Smart / Monitored |
| Input Voltage | 415V (50/60 Hz) |
| Input Plug | IEC 60309 3P+N+G 6Hr, 30A |
| Input Current (Rated) | 24A |
| Input Power Capacity | 17.3 kW |
| Outlets | 24 × IEC 60320 C13 (≤12A @240V, 15A peak) 6 × IEC 60320 C19 (≤16A @240V, 20A peak) |
| Branch Circuit Protection | 6 × 20A trip magnetic-hydraulic circuit breakers, UL 489/CSA/IEC compliant |
| Dimensions (HxWxD) | 70.1 in × 1.75 in × 2.25 in (1781 × 45 × 58 mm) |
| Environmental | Operating: 0°C–60°C, 8–90% RH non-condensing Storage: -30°C–80°C |
| Communications | 10/100/1000 Mbps Ethernet, RS-232, Link port, SNMP v2/v3, HTTPS/SSH, Syslog, LDAP, RADIUS, TACACS+ |
| Monitoring Features | PIPS® Inlet Power Sensing, per-phase LED current display, temperature/humidity monitoring (with probes) |
| Certifications | UL 62368-1, CSA C22.2 No. 62368-1, FCC Part 15 Class A, CAN ICES-003 Class A |
| Warranty | 2-Year Limited Warranty (extended support available) |
