Description
The Server Technology® PRO2 Switched POPS PDU (C2WG48TE-4PAE2M99) is a high-density power distribution unit designed for maximum reliability, control, and visibility in modern data centers. Equipped with PIPS® (Per Inlet Power Sensing) and POPS® (Per Outlet Power Sensing) technologies, it provides billing-grade power measurements at both the input and individual outlet levels.
This PDU features HDOT Cx outlets, a hybrid of C13 and C19, ensuring compatibility with both C14 and C20 plugs. It supports network monitoring via HTTP(S), SNMP, SSH, and more, with redundant connectivity through a hot-swap network card and Star multi-linking, enabling management of up to four power circuits with a single IP.
Designed for demanding environments, the unit is rated for 60°C operation, includes branch circuit protection, and supports environmental monitoring with external temperature/humidity probes. The alternating-phase outlet layout improves airflow, reduces cord clutter, and simplifies load balancing in high-density racks.
| Category | Details |
|---|---|
| Brand | Server Technology (Legrand) |
| Product Line | PRO2 Switched POPS |
| Model / SKU | C2WG48TE-4PAE2M99 (Primary) |
| Form Factor | Vertical (80.0 in x 2.2 in x 2.5 in / 2032mm x 56mm x 64mm) |
| Input Voltage | 400V (50/60Hz) |
| Input Plug | 230/400V Wye 32A IEC 60309 3P+N+PE 6Hr |
| Input Current | 32A |
| Power Capacity | 22 kW |
| Outlets | 30 × IEC 60320 C13 (≤10A @ 230V L-N) 18 × Cx hybrid (≤16A @ 230V L-N) |
| Outlet Features | HDOT Cx hybrid outlets (C13/C19), alternating-phase layout, outlet-level switching |
| Metering & Sensing | PIPS® (Per Inlet Power Sensing), POPS® (Per Outlet Power Sensing), Branch Current Monitoring |
| Communications | 10/100/1000 Mbps Ethernet, RS-232 serial, Web GUI, CLI, SNMPv2c/v3, HTTP/HTTPS, SSH, Telnet |
| Environmental Support | 2 external T/H probes (10ft), SNMP/email alerts |
| Branch Circuit Protection | UL 489 / IEC 60947-2 compliant, 2-pole 20A breakers, 6 branch circuits |
| Operating Temp. | 0°C to 60°C (32°F to 140°F) |
| Certifications | EN/IEC 62368-1 (TUV), CE, UKCA, RoHS, EMC compliance (EN 55032/35, EN 61000-3-2/3) |
| Mounting Options | Button mounts (included), flexible/custom mounting |
| Warranty | 2-Year Limited (Extended support available) |
| Optional Accessories | EMTH-2-10 Temp/Humidity Probe, EMCU-1-1C Environmental Monitor, PRO2 Link Kits, Cable Retention Devices |
