Description
The Server Technology® PRO2 STV-6509K Switched POPS PDU delivers advanced power distribution and precise monitoring for mission-critical data centers. Designed with PIPS® and POPS® technology, it offers billing-grade accuracy for power measurement at both inlet and outlet levels. IT administrators gain full control with outlet-level switching, branch circuit protection, and real-time monitoring of voltage, current, active power, power factor, and energy usage.
This PDU supports hot-swap network cards, star multi-linking for up to four circuits under one IP, and temperature/humidity monitoring with optional probes. Its robust build includes UL/IEC 62368-1 certified protection and a flexible 90° rotatable power cord for easy deployment. Perfect for high-density rack environments, the STV-6509K ensures reliability, efficiency, and intelligent power management in demanding enterprise applications.
| Category | Details |
|---|---|
| Manufacturer | Server Technology, Inc. (Legrand) |
| Product Series | PRO2 |
| Model / SKU | STV-6509K (Primary), SEV-6509K (Link) |
| PDU Type | Switched POPS (Per Outlet Power Sensing) |
| Phase | Three Phase |
| Input Voltage | 400V, 50/60 Hz |
| Input Plug | 230/400V Wye 32A IEC 60309 3P+N+PE 6Hr |
| Input Current | 32A (Rated 32A) |
| Input Power Capacity | 22.0 kW |
| Outlets | (30) IEC 60320 C13 ≤10A @230V; (6) IEC 60320 C19 ≤16A @230V |
| Branch Protection | UL 489 compliant, 1-pole 20A trip breakers, 6 branch circuits |
| Dimensions (HxWxD) | 70.0in x 2.19in x 2.25in (1778mm x 56mm x 58mm) |
| Operating Environment | 32°F–122°F (0°C–50°C), 8–90% RH non-condensing |
| Storage Environment | -22°F–176°F (-30°C–80°C), up to 50,000ft elevation |
| Power Draw | <10W unloaded |
| Communications | 10/100/1000 Mbps Ethernet, RS-232 serial, Link port (RJ-12) |
| Protocols Supported | HTTP/HTTPS, SSH, Telnet, SNMP v2/v3, LDAP/LDAPS, TACACS+, RADIUS, FTP/SFTP |
| Certifications | EN/IEC 62368-1, CE, UKCA, RoHS, EMC (EN 55032/35, EN 61000-3-2/3) |
| Warranty | 2-Year Limited (extended options available) |
| Optional Accessories | Temperature/humidity probes, environmental monitors, PRO2 link kits, mounting brackets, cable retention devices |
